Assembly
100%

331-8164 ENCLOSURE GP-GENERATORS/N KEN1-UP

Group No: 331-8164
Part NumberPart NameQty
23544511 BOLT-FLANGE HEAD (M6X1X16-MM)18
29286792 BRACKET GP-TERMINAL1
31145633 CHANNEL AS1
3115887PLATE2
33181654 BOX AS-TERMINAL1
33181735 PLATE2
33181746 PLATE2
33181757 PLATE2
19847768 WASHER-HARD (8.8X20X8-MM THK)6
19847789 WASHER-HARD (13.5X30X12-MM THK)8
5C289010 NUT (M6X1-THD)5
5C726111 NUT (M8X1.25-THD)18
5P107612 WASHER-HARD (13.5X30X4-MM THK)8
6V768713 LOCKNUT (M12X1.75-THD)24
8E957114 WASHER-HARD (8.8X16X7-MM THK)4
8T413815 BOLT (M6X1X20-MM)5
8T418316 BOLT (M12X1.75X40-MM)24
8T422317 WASHER-HARD (13.5X25.5X3-MM THK)40
8T422418 WASHER-HARD (8.8X16X2-MM THK)22
8T754719 BOLT (M8X1.25X30-MM)10
9X825620 WASHER (6.6X12X2-MM THK)10
5P411621 WASHER-HARD (8.8X20.5X2-MM THK)4
8T490822 BOLT (M8X1.25X25-MM)8
354537023 PLATE AS2
6V9632NUT-WELD (M6X1-THD)1
