System And Components
289-8648 ALTERNATOR GP-CHARGING -WITH AIR CONDITIONINGS/N JCP1-UP; JCS1-UP
Group No: 289-8648
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1900643 | 1 BELT TENSIONER GP | 1 | |
| 3991485 | 2 ALTERNATOR | 1 | |
| 2193303 | 3 BELT-SERPENTINE (ALTERNATOR) | 1 | |
| 2653841 | 4 BRACKET | 1 | |
| 3907340 | 5 PULLEY-ALTERNATOR (8-GROOVE) | 1 | |
| 3057881 | 6 BRACKET AS-ALTERNATOR | 1 | |
| 1619820 | PIN | 2 | |
| 5C7261 | 7 NUT (M8X1.25-THD) | 1 | |
| 7X2541 | 8 BOLT (M8X1.25X140-MM) | 1 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4172 | 11 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4185 | 12 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T5005 | 15 BOLT (M10X1.5X70-MM) | 1 | |
| 8T7547 | 16 BOLT (M8X1.25X30-MM) | 1 |
