System And Components
564-2765 LUBRICATION GP-AUTOMATICS/N SKH1-UP
Group No: 564-2765
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0038470 | 1 TEE-PIPE | 1 | |
| 0046683 | 2 FITTING | 2 | |
| 0115224 | 3 BUSHING-REDUCER | 1 | |
| 1243019 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1358573 | 5 BOLT AS | 1 | |
| 1358575 | 6 BOLT AS | 3 | |
| 1448344 | 7 SPACER (11X19X20-MM THK) | 9 | |
| 2057299 | 8 CLIP (LOOP) | 23 | |
| 2067013 | 9 FASTENER | 12 | |
| 2287088 | 10 SEAL-O-RING | 8 | |
| 2287090 | 11 SEAL-O-RING | 2 | |
| 2310336 | 12 STUD-TAPERLOCK (M10X1.5X70-MM) | 2 | |
| 2533874 | 13 HOSE AS | 2 | |
| 2622603 | 14 SPACER (13.5X30X16-MM THK) | 1 | |
| 2684779 | 15 STUD-TAPERLOCK (M10X1.5X95-MM) | 1 | |
| 2695352 | 16 VALVE GP-LUBE DISTRIBUTION (4-INJECTOR) | 1 | |
| 2695353 | 17 VALVE GP-LUBE DISTRIBUTION (5-INJECTOR) | 1 | |
| 2F1336 | 18 FITTING-HEAD | 1 | |
| 2N1287 | 19 ELBOW-FLARED | 6 | |
| 2P1279 | 20 LOCKNUT (9/16-18-THD) | 2 | |
| 2R1939 | 21 CLIP (LOOP) | 4 | |
| 2W1501 | 22 BRACKET | 1 | |
| 3107300 | 23 CLIP (LOOP) | 3 | |
| 3293356 | 24 NUT (M12X1.75-THD) | 3 | |
| 3445675 | 25 NUT (M10X1.5-THD) | 25 | |
| 3501571 | 26 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3526494 | 27 ADAPTER AS | 6 | |
| 8C6865 | CONNECTOR | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3526496 | 28 ADAPTER AS | 1 | |
| 8C6871 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3526504 | 29 ELBOW AS | 12 | |
| 7X0492 | ELBOW | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3537957 | 30 GROMMET | 4 | |
| 3J5390 | 31 PLUG (3/8-18-THD) | 1 | |
| 3M7045 | 32 PLUG (3/4-14 NPT-THD) | 8 | |
| 4205299 | 33 CLIP (LOOP) | 10 | |
| 4317913 | 34 STRAP | 2 | |
| 4357441 | 35 PLATE-COVER | 9 | |
| 4361789 | 36 BRACKET | 2 | |
| 4392898 | 37 SPACER (13.8X30X30-MM THK) | 1 | |
| 4423493 | 38 ADAPTER AS | 1 | |
| 6V9169 | NUT (13/16-16-THD) | 1 | |
| 3526495 | TEE AS | 1 | |
| 8T6895 | TEE-UNION | 1 | |
| 2287090 | SEAL-O-RING | 3 | |
| 4423496 | 39 FILM-IDENTIFICATION (LABEL) | 1 | |
| 4423497 | 40 FILM-IDENTIFICATION (LABEL) | 1 | |
| 4423499 | 41 ADAPTER AS | 1 | |
| 2115237 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 4423514 | 42 ADAPTER AS | 1 | |
| 2T2396 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 4501725 | 43 BRACKET | 3 | |
| 4616750 | 44 HOSE AS | 1 | |
| 4648799 | 45 COVER AS | 1 | |
| 4689671 | 46 CLAMP-HALF | 18 | |
| 4792171 | 47 BOLT AS | 16 | |
| 4792172 | 48 BOLT AS | 8 | |
| 4883974 | 49 BOLT AS | 1 | |
| 4923592 | 50 BOLT-12 POINT HEAD (M10X1.5X60-MM) | 4 | |
| 4934374 | 51 BRACKET | 2 | |
| 5002988 | 52 BRACKET | 1 | |
| 5736411 | 53 HOSE AS | 1 | |
| 5736412 | 54 HOSE AS | 1 | |
| 5736413 | 55 HOSE AS | 1 | |
| 5736414 | 56 HOSE AS | 1 | |
| 5736415 | 57 HOSE AS | 1 | |
| 5736416 | 58 HOSE AS | 1 | |
| 5736417 | 59 HOSE AS | 1 | |
| 5736418 | 60 HOSE AS | 1 | |
| 5736419 | 61 HOSE AS | 1 | |
| 5736420 | 62 HOSE AS | 1 | |
| 5736421 | 63 HOSE AS | 1 | |
| 5736422 | 64 HOSE AS | 1 | |
| 5740322 | 65 TUBE AS | 1 | |
| 5741275 | 66 BRACKET AS | 1 | |
| 5758483 | 67 HOSE AS | 1 | |
| 5P1076 | 68 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P4295 | 69 CLIP | 3 | |
| 5P7462 | 70 CLIP (SLOT) | 4 | |
| 5P7463 | 71 CLIP (TAB) | 4 | |
| 5P7468 | 72 CLIP (SLOT) | 4 | |
| 5P7469 | 73 CLIP (TAB) | 4 | |
| 5P7470 | 74 CLIP (SLOT) | 4 | |
| 5P7471 | 75 CLIP (TAB) | 4 | |
| 6V0683 | 76 GROMMET | 4 | |
| 6V1581 | 77 CLIP (SLOT) | 2 | |
| 6V1582 | 78 CLIP (TAB) | 2 | |
| 6V1875 | 79 GROMMET | 4 | |
| 6V6782 | 80 CLIP (SLOT) | 1 | |
| 6V6783 | 81 CLIP (TAB) | 1 | |
| 6V8986 | 82 ELBOW | 2 | |
| 7X7729 | 83 WASHER (11X25X3-MM THK) | 25 | |
| 8C8408 | 84 ELBOW | 4 | |
| 8T1887 | 85 CLIP (SLOT) | 4 | |
| 8T1888 | 86 CLIP (TAB) | 4 | |
| 8T2525 | 87 GROMMET | 4 | |
| 8T4121 | 88 WASHER-HARD (11X21X2.5-MM THK) | 43 | |
| 8T4139 | 89 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4172 | 90 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4182 | 91 BOLT (M10X1.5X45-MM) | 5 | |
| 2592627 | 92 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4184 | 93 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4185 | 94 BOLT (M10X1.5X50-MM) | 4 | |
| 8T4186 | 95 BOLT (M10X1.5X40-MM) | 9 | |
| 8T4192 | 96 BOLT (M12X1.75X25-MM) | 3 | |
| 1837121 | 97 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 98 WASHER-HARD (13.5X25.5X3-MM THK) | 11 | |
| 3621320 | 99 BOLT (M12X1.75X35-MM) | 2 | |
| 8T6466 | 100 BOLT (M10X1.5X60-MM) | 20 | |
| 8T8917 | 101 BOLT (1/2-13X1.25-IN) | 1 | |
| 9C2741 | 102 SPACER (13.94X17.14X34-MM THK) | 1 | |
| 9L5125 | 103 ELBOW | 4 |
