Assembly
100%

308-1857 STARTING MOTOR GP-AIRFOR USE WITH LH SERVICE ENGINE

Group No: 308-1857
Part NumberPart NameQty
3N72811 HOSE AS2
3S20932 STRAP-CABLE12
4N34113 VALVE GP-RELAY (AIR STARTING MOTOR)1
4W51064 STARTING MOTOR GP-AIR1
5N27285 ELBOW1
5N87436 BRACKET1
6F59857 HOSE AS1
8N84468 ELBOW1
8N84479 ELBOW1
8N845110 GASKET1
8N845211 GASKET1
8N848812 SILENCER-AIR STARTING1
8T676213 PLUG-PIPE (1/2-14-THD)1
9Y608914 GASKET1
172020815 LUBRICATOR GP-AIR MOTOR1
352650416 ELBOW AS1
7X0492ELBOW1
2287088SEAL-O-RING1
308305117 TUBE AS1
308940218 HARNESS AS-WIRING1
6I4347BOOT (4-PIN)2
9X3401PIN-CONNECTOR (16-GA TO 18-GA)2
1261767PIN-CONNECTOR (14-GA TO 16-GA)2
1945226TERMINAL AS (16-GA)2
1945227TERMINAL AS (14-GA)2
1028802KIT-RECEPTACLE (2-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)1
309908119 VALVE AS-SOLENOID (AIR START)1
176254320 BOLT-12 POINT HEAD (5/8-11X1.75-IN)3
0S159421 BOLT (3/8-16X1-IN)2
3L899222 NIPPLE-PIPE1
3P182323 ADAPTER-PIPE1
4P742824 CLIP (LADDER)1
4P758125 CLIP (LADDER)1
4P758226 CLIP (LADDER)1
4P813427 CLIP (LADDER)6
4S639928 CONNECTOR1
5B764329 NIPPLE-PIPE1
5B766130 FITTING1
5L253431 U-BOLT1
5M289432 WASHER-HARD (10.2X18.5X2.5-MM THK)2
8T422333 WASHER-HARD (13.5X25.5X3-MM THK)2
6B368534 ELBOW2
6F885735 NIPPLE-PIPE1
6K101936 NIPPLE-PIPE1
6K197237 ELBOW-FLARED3
6V443238 BOLT (1/2-13X4-IN)2
6V880139 NUT (3/8-16-THD)2
7D172840 CLIP3
7K118141 STRAP-CABLE2
5M306242 BOLT (3/8-16X0.75-IN)1
8T489643 WASHER-HARD (10.2X18.5X2.5-MM THK)3
8T939144 BOLT (1/2-13X3.75-IN)6
5P913545 GROMMET1
