System And Components
355-8168 LINES GP-FUELS/N KGF1-UP; FAL1-UP
Group No: 355-8168 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0379 | 1 VALVE-MANUAL (DRAIN, FUEL TANK) | 1 | |
| 4I0379 | 1A VALVE-MANUAL (FUEL SHUTOFF) | 1 | |
| 6S8620 | 2 CLAMP-HOSE | 3 | |
| 9Y8389 | 3 GASKET (FUEL PRIMING PUMP) | 2 | |
| 0037764 | 4 END-HOSE | 4 | |
| 0951386 | 5 CLAMP-HOSE | 8 | |
| 1358572 | 6 BOLT AS | 1 | |
| 1375541 | 7 PUMP GP-FUEL PRIMING | 1 | |
| 0617539 | SEAL-O-RING | 1 | |
| 2293218 | VALVE AS | 2 | |
| 1503024 | 8 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P4924 | ELBOW | 1 | |
| 1702901 | 9 GROMMET | 1 | |
| 2029871 | 10 BASE AS | 1 | |
| 7E5346 | VALVE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2506183 | 11 ADAPTER | 1 | |
| 2936789 | 12 BRACKET AS | 1 | |
| 3077804 | 14 HOSE AS | 1 | |
| 4I9523 | BAND-MARKER (BLUE, L3) | 1 | |
| 4I9525 | BAND-MARKER (ORANGE, R1) | 1 | |
| 5P1442 | HOSE (337-CM) | ||
| 3435527 | 15 BOWL AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5F9144 | SEAL-O-RING | 1 | |
| 8F7219 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 3558164 | 16 HOSE AS | 1 | |
| 4I9522 | BAND-MARKER (YELLOW, L2) | 1 | |
| 4I9527 | BAND-MARKER (GREEN, R3) | 1 | |
| 5P1442 | HOSE (400-CM) | ||
| 3558198 | 17 HOSE | 1 | |
| 1343299 | 18 GROMMET | 1 | |
| 1488313 | 19 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2M9780 | 20 SEAL-O-RING | 1 | |
| 2R1498 | 21 GROMMET | 3 | |
| 3261643 | 22 FILTER AS-WATER SEP & FUEL | 1 | |
| 2208678 | SEAL-RING | 1 | |
| 5K8451 | 23 CLIP (LOOP) | 12 | |
| 5P0537 | 24 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6D4636 | 25 CLIP (LOOP) | 3 | |
| 6V2606 | 26 ADAPTER | 1 | |
| 6V5048 | 27 SEAL-O-RING | 4 | |
| 7X2501 | 28 BOLT (1/4-20X1.25-IN) | 1 | |
| 7Y8167 | 29 GROMMET (50-MM ID) | 1 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 25 | |
| 8T4133 | 31 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 32 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4137 | 33 BOLT (M10X1.5X20-MM) | 18 | |
| 8C6561 | 34 BOLT (5/16-18X1.375-IN) | 1 | |
| 8T4195 | 35 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4205 | 36 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T4224 | 37 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4971 | 38 BOLT (M6X1X30-MM) | 1 | |
| 8T7547 | 39 BOLT (M8X1.25X30-MM) | 3 | |
| 9M8406 | 40 CLIP (LOOP) | 10 | |
| 9S8002 | 41 PLUG (7/16-20-THD) | 4 | |
| 5P1442 | 42 HOSE (161-CM) | ||
| 5P1442 | 42A HOSE (30-CM) | ||
| 5P1442 | 42B HOSE (515-CM) | ||
| 4I9521 | 43 BAND-MARKER (RED, L1) | 2 |
