System And Components
147-5283 LINES GP-FRONTS/N ADC1-UP; AEJ1-UP
Group No: 147-5283
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1604086 | 1 HOSE AS | 4 | |
| 7J9108 | 2 SEAL-O-RING | 17 | |
| 8T4192 | 3 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 1087178 | 5 PLATE | 1 | |
| 1489120 | 6 TUBE AS | 1 | |
| 1489119 | 7 TUBE AS | 1 | |
| 1275856 | 8 HOSE AS | 1 | |
| 6V9746 | 9 SEAL-O-RING | 7 | |
| 1116710 | 10 HOSE AS | 1 | |
| 4I5648 | 11 HOSE AS | 1 | |
| 5K9090 | 12 SEAL-O-RING | 2 | |
| 8T4910 | 13 BOLT (M12X1.75X60-MM) | 1 | |
| 0995408 | 14 CLAMP | 1 | |
| 4I1077 | 15 HOSE AS | 1 | |
| 0964884 | 16 LOCKNUT (M12X1.75-THD) | 1 | |
| 8T4648 | 17 BOLT (M12X1.75X70-MM) | 1 | |
| 9F2167 | 18 SCREW-PURGE (3/8-24X1.164-IN) | 1 | |
| 1095815 | 19 CONNECTOR | 1 | |
| 3D2824 | 20 SEAL-O-RING | 7 | |
| 6V8716 | 21 CONNECTOR (STRAIGHT) | 1 | |
| 7M8485 | 22 SEAL-O-RING | 4 | |
| 1095822 | 23 CONNECTOR | 1 | |
| 9S4181 | 24 PLUG (1-5/16-12-THD) | 2 | |
| 6V8637 | 25 CONNECTOR | 2 | |
| 1095823 | 26 CONNECTOR | 1 | |
| 6V8635 | 27 CONNECTOR | 1 | |
| 0931296 | 28 CLAMP | 1 | |
| 1158770 | 29 HOSE AS | 1 | |
| 1192763 | 30 HOSE AS | 1 | |
| 6V8713 | 31 CONNECTOR | 2 | |
| 6V9510 | 32 PLUG (1-14-THD) | 4 | |
| 6V9511 | 33 PLUG (1-3/16-12-THD) | 3 | |
| 6V9512 | 34 PLUG (1-7/16-12-THD) | 1 |
