System And Components
316-8831 GUARD GP-FRONT WINDOWS/N MND1-UP; JAT1-UP
Group No: 316-8831
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D4822 | 1 RING-RETAINING | 4 | |
| 6I5976 | 2 SHIM (1-MM THK) | 4 | |
| 7Y8561 | 3 BUMPER | 2 | |
| 8Y5745 | 4 LATCH AS | 2 | |
| 1027688 | 5 KNOB | 2 | |
| 1863782 | 6 BOSS | 2 | |
| 2014534 | 7 BOLT (M16X2X26-MM) | 2 | |
| 3361159 | 8 SUPPORT AS | 1 | |
| 3361160 | 9 SUPPORT AS | 1 | |
| 3361161 | 10 GUARD AS | 1 | |
| 3361163 | 11 BRACKET AS | 2 | |
| 3467367 | 12 PEDAL AS | 1 | |
| 3467370 | 13 PEDAL AS | 1 | |
| 3423715 | 14 BRACKET AS | 1 | |
| 3423717 | 15 BRACKET AS | 1 | |
| 3423723 | 16 SPRING AS-GAS (FRONT WINDOW GUARD) | 2 | |
| 6V7357 | 17 BOLT (M6X1X25-MM) | 8 | |
| 7Y0623 | 18 LOCKNUT (M16X2-THD) | 2 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4133 | 20 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4195 | 22 BOLT (M10X1.5X30-MM) | 8 | |
| 9X6165 | 23 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 9X8256 | 24 WASHER (6.6X12X2-MM THK) | 6 | |
| 9X8257 | 25 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 2190305 | 26 FILM-WARNING (NO WELD, NO DRILL, READ OMM) | 1 |
