Assembly
100%

490-4841 GAUGE GP-OIL LEVEL (DIPSTICK) -FILLERS/N BR91-10000

Group No: 490-4841
Part NumberPart NameQty
8T41361 BOLT (M10X1.5X25-MM)6
8T41212 WASHER-HARD (11X21X2.5-MM THK)6
8T41383 BOLT (M6X1X20-MM)2
9M01644 CLAMP-HOSE1
9M29045 CLAMP-HOSE1
9X82566 WASHER (6.6X12X2-MM THK)2
13060017 BODY AS1
36938698 CAP AS-ENGINE OIL FILLER1
3570147FILM-IDENTIFICATION (OIL FILL, READ OMM)1
1240506SEAL1
49204599 PLATE AS1
492046010 PLATE AS1
502351411 HOSE1
512610712 GAUGE AS-OIL LEVEL (DIPSTICK)1
6I1497SEAL1
2287089SEAL-O-RING1
2922491CLIP2
7D155313 CLIP1
