System And Components
503-9758 TANK & FILTER GP-HYDRAULICS/N GDY1-10544
Group No: 503-9758
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4196 | 1 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4910 | 2 BOLT (M12X1.75X60-MM) | 4 | |
| 5C9553 | 3 BOLT (M6X1X16-MM) | 3 | |
| 1757896 | 4 SEAL-O-RING | 1 | |
| 1U2827 | 5 GUIDE-VALVE (HYDRAULIC TANK DRAIN) | 1 | |
| 4J0527 | 6 SEAL-O-RING | 1 | |
| 5M2057 | 7 SEAL-O-RING | 1 | |
| 6D9157 | 8 SEAL-O-RING | 1 | |
| 7B3039 | 9 SPRING | 1 | |
| 8J8782 | 10 BODY-DRAIN VALVE (HYDRAULIC TANK) | 1 | |
| 8J8783 | 11 VALVE-DRAIN (HYDRAULIC TANK) | 1 | |
| 8T0267 | 12 BOLT-SOCKET HEAD (M6X1X12-MM) | 2 | |
| 8T3298 | 13 SEAL-RECTANGULAR | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 9J7031 | 15 PLUG-DRAIN (HYDRAULIC TANK) | 1 | |
| 0951730 | 16 SEAL-O-RING | 1 | |
| 1053484 | 17 BOLT-SOCKET HEAD (M10X1.5X25-MM) | 4 | |
| 1653256 | 18 PIPE AS | 1 | |
| 1756176 | 19 SEAL-O-RING | 1 | |
| 2566453 | 20 SENSOR-TEMPERATURE (2-PIN)(HYDRAULIC TANK OIL) | 1 | |
| 3476081 | 21 GAUGE GP-SIGHT (HYDRAULIC OIL LEVEL) | 1 | |
| 4916075 | 22 FILTER GP-OIL (HYDRAULIC CASE DRAIN)(HYDRAULIC TANK) | 1 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 4481376 | 23 SCREEN GP-HYDRAULIC | 1 | |
| 5049586 | 24 SWITCH AS-DIFF PRESSURE (RETURN FILTER) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1927510 | SEAL-O-RING | 1 | |
| 5124914 | SEAL-FACE | 1 | |
| 5049687 | 25 FILTER GP-OIL (HYDRAULIC RETURN)(HYDRAULIC TANK) | 1 | |
| 5254107 | 26 PIPE | 1 | |
| 5285916 | 27 PIPE AS | 1 | |
| 5407019 | 28 BREATHER GP (HYDRAULIC TANK)(HYDRAULIC TANK) | 1 | |
| 5198217 | 29 COVER AS | 1 | |
| 3K0360 | 30 SEAL-O-RING | 1 | |
| 8T4137 | 32 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4223 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9X8256 | 34 WASHER (6.6X12X2-MM THK) | 3 | |
| 5567339 | 35 TANK GP-HYDRAULIC | 1 |
