System And Components
477-7565 CAB GP -EXTERIORS/N GDY1-UP
Group No: 477-7565
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I3090 | 1 SEAL | 9 | |
| 7Y8561 | 2 BUMPER | 1 | |
| 1566480 | 3 SEAL | 2 | |
| 1566599 | 4 STRIKER | 1 | |
| 1677042 | 5 SEAL | 3 | |
| 3949460 | 6 MIRROR GP | 1 | |
| 1892864 | 7 SCREW-FLAT HEAD (M8X1.25X30-MM) | 2 | |
| 4512175 | 8 WASHER-HARD (17.5X30X3.5-MM THK) | 1 | |
| 4512180 | 9 BOLT (M16X2X35-MM) | 1 | |
| 4533454 | 10 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 4578759 | 11 BOLT (M10X1.5X20-MM) | 3 | |
| 5639148 | 12 LATCH AS | 1 | |
| 5662225 | 13 HANDRAIL AS (FRONT) | 1 | |
| 4886488 | 14 HANDRAIL AS (SIDE) | 1 | |
| 4886538 | 15 LEVER GP-CAB DOOR | 1 | |
| 5268575 | LEVER AS | 1 | |
| 5268576 | CABLE AS | 1 | |
| 5000732 | 16 PLATE | 1 | |
| 5000962 | 17 INSULATION | 1 | |
| 5000963 | 18 INSULATION | 1 | |
| 5115969 | 19 BUMPER | 1 | |
| 5164923 | 20 COVER | 1 | |
| 5662224 | 21 MOUNTING GP-MIRROR | 1 | |
| 3B4504 | LOCKWASHER | 2 | |
| 9X6153 | BOLT (M6X1X10-MM) | 2 | |
| 5247742 | 22 COVER GP-CAB | 1 | |
| 5268550 | 23 BRACKET | 1 | |
| 5268551 | 24 PLATE | 1 | |
| 1270580 | 25 SCREW-FLAT HEAD (M8X1.25X20-MM) | 2 | |
| 1636795 | 26 STRAP-CABLE | 3 | |
| 1R5998 | 27 LOCKWASHER | 4 | |
| 3445675 | 28 NUT (M10X1.5-THD) | 2 | |
| 3E8020 | 29 SCREW-TRUSS HEAD (M6X1X25-MM) | 4 | |
| 7X0578 | 30 WASHER-HARD (10.2X32X2.5-MM THK) | 1 | |
| 7X7729 | 31 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 33 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4224 | 34 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X2041 | 35 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 1 | |
| 9X2044 | 36 SCREW-TRUSS HEAD (M6X1X16-MM) | 6 | |
| 8T4200 | 37 BOLT (M8X1.25X16-MM) | 2 |
