System And Components
488-6560 CONSOLE GP-OPERATORS/N GDY1-UP
Group No: 488-6560
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y8561 | 1 BUMPER | 1 | |
| 4876659 | 2 ARMREST GP (DELUXE) | 1 | |
| 4878455 | 3 CONTROL GP-JOYSTICK | 2 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 3617886 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 4886534 | 4 HOLDER GP-CUP | 1 | |
| 4886551 | 5 CONSOLE GP-OPERATOR (STORAGE) | 1 | |
| 4886570 | 6 CONSOLE GP-OPERATOR (SECONDARY) | 1 | |
| 4956057 | 7 BUSHING | 6 | |
| 5000884 | 8 DAMPER | 1 | |
| 5116016 | 9 CONSOLE GP-OPERATOR (RH) | 1 | |
| 5116023 | 10 CONSOLE GP-OPERATOR (LH) | 1 | |
| 5208286 | 11 STRIKER | 1 | |
| 5208293 | 12 SPACER (18.5X34X3.1-MM THK) | 1 | |
| 5208294 | 13 BRACKET | 2 | |
| 3320195 | 14 CLIP | 2 | |
| 3T0849 | 15 BOLT-SOCKET HEAD (M6X1X25-MM) | 6 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 1 | |
| 9X2043 | 18 SCREW-TRUSS HEAD (M6X1X14-MM) | 6 | |
| 9X6165 | 19 WASHER (6.5X22X2.5-MM THK) | 4 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 6 |
