System And Components
484-8019 WINDOW GP-CAB -FRONT, UPPERS/N JFW1-UP
Group No: 484-8019
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1519576 | 1 ROLLER | 1 | |
| 3346482 | 2 ROLLER | 3 | |
| 4386968 | 3 HANDLE GP-WINDOW (LH) | 1 | |
| 4386969 | 4 HANDLE GP-WINDOW (RH) | 1 | |
| 4865450 | 5 GLASS (TEMPERED) | 1 | |
| 4865457 | 6 SEAL | 1 | |
| 4876744 | 7 FRAME AS | 1 | |
| 4876745 | 8 BRACKET AS (BOTTOM, RH) | 1 | |
| 4876746 | 9 BRACKET AS (BOTTOM, LH) | 1 | |
| 4876747 | 10 BRACKET AS (TOP, LH) | 1 | |
| 4876748 | 11 BRACKET AS (TOP, RH) | 1 | |
| 4876847 | 12 PIN | 1 | |
| 4876849 | 13 SEAL | 1 | |
| 5000744 | 14 BLOCK | 1 | |
| 1361613 | 15 BOLT-SOCKET HEAD (M6X1X30-MM) | 4 | |
| 9X2044 | 16 SCREW-TRUSS HEAD (M6X1X16-MM) | 12 | |
| 9X6155 | 17 BOLT-SOCKET HEAD (M6X1X16.7-MM) | 2 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 4 |
