System And Components
511-6023 CONSOLE GP-OPERATOR -LHS/N YCP1-UP
Group No: 511-6023
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4876653 | 1 COVER AS | 1 | |
| 2346579 | NUT-SPEED | 1 | |
| 5115919 | CLIP | 5 | |
| 4876654 | 2 COVER AS | 1 | |
| 2346579 | NUT-SPEED | 1 | |
| 5115919 | CLIP | 3 | |
| 4876832 | 3 COVER | 1 | |
| 4876838 | 4 COVER | 1 | |
| 4987728 | 5 COVER AS | 1 | |
| 5115982 | COVER | 3 | |
| 5000930 | 6 COVER AS-CONSOLE | 1 | |
| 5000933 | 7 SUPPORT AS (LH) | 1 | |
| 5115921 | 8 BAR AS | 1 | |
| 5682311 | 9 HANDLE AS | 1 | |
| 5116026 | 10 SWITCH GP-POSITION (HYDRAULIC LOCK) | 1 | |
| 4I3038 | WASHER (3.3X8X0.5-MM THK) | 2 | |
| 1114799 | SWITCH AS-LIMIT (HYDRAULIC LOCK) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 5P5998 | TUBE (0.3-M) | ||
| 1209027 | SCREW-PAN HEAD (M3X0.5X16-MM) | 2 | |
| 4876813 | LATCH AS | 1 | |
| 5116027 | 11 BRACKET AS | 1 | |
| 5164930 | 12 COVER | 1 | |
| 5208227 | 13 SCREW-MACHINE (M4X0.7X2.3-MM) | 1 | |
| 5208253 | 14 SCREW-TAPPING | 2 | |
| 5662193 | 15 SCREW-MACHINE (M4X0.7X10-MM) | 3 | |
| 5208291 | 16 SCREW-MACHINE (M4X0.7X15-MM) | 2 | |
| 5208292 | 17 SPACER (4.2X6X3.3-MM THK) | 2 | |
| 5268631 | 18 RIVET | 1 | |
| 3E8020 | 19 SCREW-TRUSS HEAD (M6X1X25-MM) | 2 | |
| 9X2042 | 20 SCREW-TRUSS HEAD (M6X1X12-MM) | 3 | |
| 9X2043 | 21 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 |
