System And Components
388-0067 COUPLER GP-QUICK -B-LINKAGES/N KPE1-UP
Group No: 388-0067
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4137 | 1 BOLT (M10X1.5X20-MM) | 1 | |
| 1598036 | 2 FILM-WARNING (READ OMM) | 1 | |
| 3555804 | 3 PLUG | 2 | |
| 3880084 | 4 LATCH | 1 | |
| 3880085 | 5 ROCKER ARM (LH) | 1 | |
| 3880086 | 6 ROCKER ARM (RH) | 1 | |
| 3880088 | 7 SPRING-SPACER | 2 | |
| 3880090 | 8 SPRING-GUIDE | 2 | |
| 3880091 | 9 PIN | 1 | |
| 3880099 | 10 PIN | 1 | |
| 3880105 | 11 HOSE AS | 3 | |
| 3880110 | 12 HOSE AS | 1 | |
| 3886876 | 13 PIN | 1 | |
| 3909505 | 14 CYLINDER GP-COUPLER (B-LINKAGE) | 1 | |
| 3937499 | 15 HOSE AS | 1 | |
| 4246681 | 16 SPRING | 2 | |
| 4405314 | 17 HOSE AS | 1 | |
| 4405315 | 18 HOSE AS | 1 | |
| 4467944 | 19 PIN | 1 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 5 | |
| 4583274 | 21 PLATE-COVER | 1 | |
| 4583275 | 22 PLATE | 1 | |
| 4631603 | 23 WEDGE | 1 | |
| 0960015 | 24 RING-RETAINING | 4 | |
| 2D6398 | 25 RING-RETAINING | 2 | |
| 2P1279 | 26 LOCKNUT (9/16-18-THD) | 2 | |
| 3496114 | 27 PIN | 1 | |
| 3J1907 | 28 SEAL-O-RING | 1 | |
| 3J7354 | 29 SEAL-O-RING | 1 | |
| 4D1322 | 30 RING-RETAINING | 2 | |
| 4D7794 | 31 CLIP | 2 | |
| 4J5477 | 32 SEAL-O-RING | 3 | |
| 3H0120 | 33 ELBOW | 2 | |
| 5B0935 | 34 FITTING-GREASE | 7 | |
| 5P9436 | 35 PLUG | 2 | |
| 6J7836 | 36 RING-SNAP | 2 | |
| 6V8397 | 37 SEAL-O-RING | 3 | |
| 6V8636 | 38 CONNECTOR | 1 | |
| 6V8647 | 39 CONNECTOR | 1 | |
| 6V8979 | 40 ELBOW | 1 | |
| 6V8980 | 41 ELBOW | 1 | |
| 6V9168 | 42 NUT (11/16-16-THD) | 2 | |
| 6V9828 | 43 CAP (ORFS) | 1 | |
| 6V9829 | 44 CAP (ORFS) | 1 | |
| 8T4121 | 45 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 4583267 | 46 COUPLER AS | 1 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 1 | |
| 4656315 | LIFT EYE | 1 | |
| 4750019 | PIN | 12 | |
| 4767093 | PIN | 4 |
