Assembly
100%

575-4538 LINES GP-AIR CONDITIONER -R-1234YFS/N XBE1-UP

Group No: 575-4538
Part NumberPart NameQty
8T41821 BOLT (M10X1.5X45-MM)1
8T41892 BOLT (M8X1.25X20-MM)2
06725513 CLIP1
10043364 CLIP (LOOP)1
12296575 CLAMP2
20416116 STRAP-CABLE (DUAL)1
23588917 PLATE1
23590148 CLAMP-SPRING4
23785109 GROMMET1
305044110 BAND-MARKER (HS)2
305044211 BAND-MARKER (HR)2
474155312 ADAPTER1
483780013 SPACER (11X20X20-MM THK)1
484145614 STRAP-CABLE6
560951915 HOSE AS1
1217136SEAL-O-RING2
560952116 HOSE AS1
1217137SEAL-O-RING2
560952617 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
575453918 CONDENSER & MTG GP-REFRIGERANT1
575871519 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)2
575871620 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)2
8Y3795BOSS (M10X1.5X40-MM)1
575871821 HOSE AS1
1217138SEAL-O-RING2
5750561SWITCH AS-PRESSURE (REFRIGERANT)1
1858293SEAL-O-RING1
575871922 HOSE AS1
1217136SEAL-O-RING1
5750560PLUG1
575872023 HOSE AS1
1217137SEAL-O-RING1
5750559PLUG1
576767724 PLATE GP-CERTIFICATION1
5P929725 CLIP (LOOP)1
5P929926 CLIP (LOOP)1
6D164127 CLIP (LOOP)3
6D347928 CLIP (LOOP)2
6V223529 CLIP5
6V735730 BOLT (M6X1X25-MM)2
7K118131 STRAP-CABLE1
8T412132 WASHER-HARD (11X21X2.5-MM THK)18
8T413733 BOLT (M10X1.5X20-MM)17
8T422434 WASHER-HARD (8.8X16X2-MM THK)4
8T497135 BOLT (M6X1X30-MM)1
8T754736 BOLT (M8X1.25X30-MM)2
9X825637 WASHER (6.6X12X2-MM THK)3
161371838 HOSE-DRAIN2
5P076739 HOSE (385-CM)
5P076739A HOSE (370-CM)
