System And Components
451-7538 LINES GP-AUXILIARY HYDRAULIC -MEDIUM PRESSURES/N XAA1-UP; YCA1-UP
Group No: 451-7538 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931291 | 1 CLAMP | 2 | |
| 1849404 | 2 CLIP | 2 | |
| 2686914 | 3 PLATE | 1 | |
| 2943794 | 4 CLIP AS | 2 | |
| 2943795 | 5 CLIP AS | 2 | |
| 2943796 | 6 PLATE | 1 | |
| 2943797 | 7 PLATE | 1 | |
| 2981147 | 8 SPACER (14X25X60-MM THK) | 1 | |
| 3632553 | 9 CLIP AS | 2 | |
| 4536838 | 10 TUBE GP | 1 | |
| 4536843 | 11 TUBE GP | 1 | |
| 1538867 | 12 CLIP | 2 | |
| 6V8398 | 13 SEAL-O-RING | 4 | |
| 7Y4868 | 14 CLIP | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4176 | 17 BOLT (M12X1.75X90-MM) | 1 | |
| 8T4184 | 18 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4185 | 19 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4194 | 20 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 8T4244 | 22 NUT (M12X1.75-THD) | 4 | |
| 8T4648 | 23 BOLT (M12X1.75X70-MM) | 2 |
