Assembly
100%

170-9893 MOTOR GP-SWINGS/N KXD1-UP

Group No: 170-9893
Part NumberPart NameQty
09903201 BUSHING1
09903212 SEAL-LIP TYPE1
09903223 BEARING-ROLLER1
7I00574 SPRING1
09947495 PLATE-CAM1
7I00586 PLATE-RETAINER1
20033357 PISTON AS1
09965308 PLATE-FRICTION3
09965319 PLATE-SEPARATOR3
099653210 SEAL-O-RING1
099653511 PISTON-BRAKE1
6F471812 SEAL-O-RING2
099032813 SPRING16
099032914 PIN2
099033015 SPRING4
099033116 RING4
444203317 BUSHING4
099033318 PLATE-VALVE1
099033419 BEARING AS-NEEDLE1
099033520 RING-RETAINING1
123214321 BARREL AS1
194840122 HOUSING1
7I006024 PLUG2
095178425 RING-BACKUP2
095158526 SEAL-O-RING2
095158027 SEAL-O-RING2
7I006128 VALVE (CROSSOVER RELIEF)2
7I006229 SPRING2
7I006330 SLEEVE AS2
194840031 HEAD1
095159432 SEAL-O-RING4
3J190733 SEAL-O-RING2
9S419134 PLUG (9/16-18-THD)2
229099235 VALVE GP-RELIEF (SWING)2
0951594SEAL-O-RING1
8T034736 BOLT-SOCKET HEAD (M14X1.5X45-MM)4
096593337 VALVE-CHECK (MAKEUP)2
095178938 RING2
096593439 SPRING2
096593240 PLUG2
1232145KIT-SEAL (SWING MOTOR)1
