System And Components
448-9653 LINES GP-FUELS/N ZGS1-UP
Group No: 448-9653
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0379 | 1 VALVE-MANUAL (FUEL) | 1 | |
| 4I5399 | 2 GROMMET | 1 | |
| 0932068 | 3 GROMMET | 2 | |
| 3012723 | 4 CONNECTOR-HOSE | 1 | |
| 7Y8168 | 5 GROMMET | 1 | |
| 3686658 | 6 VALVE | 1 | |
| 3700928 | 7 CONNECTOR-FUEL | 2 | |
| 3779551 | 8 COUPLING | 1 | |
| 3935525 | 9 FILTER GP-PRIMARY FUEL | 1 | |
| 4392529 | 10 PLATE AS | 1 | |
| 4503573 | 11 PLATE AS | 1 | |
| 4503577 | 12 HOSE | 1 | |
| 4503578 | 13 HOSE | 1 | |
| 4503579 | 14 HOSE | 1 | |
| 4503580 | 15 HOSE | 1 | |
| 4503581 | 16 HOSE | 1 | |
| 4505400 | 17 PLATE AS | 1 | |
| 4583189 | 18 PLATE AS | 1 | |
| 4994020 | 19 HOSE | 1 | |
| 1503024 | 20 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P4924 | ELBOW | 1 | |
| 1772215 | 21 STRAP-DUAL CLAMP | 1 | |
| 3095145 | 22 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2977964 | CONNECTOR | 1 | |
| 3474416 | 23 ADAPTER | 2 | |
| 3514318 | 24 CLIP (LOOP) | 15 | |
| 3514320 | 25 CLIP (LOOP) | 11 | |
| 5P7462 | 26 CLIP (SLOT) | 2 | |
| 5P7463 | 27 CLIP (TAB) | 2 | |
| 6S8620 | 28 CLAMP-HOSE | 13 | |
| 6V0683 | 29 GROMMET | 2 | |
| 7V6571 | 30 GROMMET | 2 | |
| 8T1889 | 31 CLIP (SLOT) | 2 | |
| 8T1890 | 32 CLIP (TAB) | 2 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 32 | |
| 8T4136 | 34 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4137 | 35 BOLT (M10X1.5X20-MM) | 21 | |
| 8T4139 | 36 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4192 | 37 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4195 | 38 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 39 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 4231982 | 41 HOSE (8.7-IN) |
