System And Components
482-0864 BUCKET GP-DITCH CLEANINGS/N TFX1-UP
Group No: 482-0864 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8257 | 1 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 1598035 | 2 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 3 FILM-WARNING (READ OMM) | 1 | |
| 4823820 | 4 PIVOT AS | 1 | |
| 9R2821 | 4A BOSS (M10X1.5X15-MM) | 5 | |
| 4845091 | 4B BUSHING | 2 | |
| 4841381 | 6 PIN AS | 1 | |
| 4841382 | 7 PIN AS | 2 | |
| 4841383 | 8 PIN GP-BUCKET | 1 | |
| 4842102 | 9 CYLINDER GP-BUCKET (LH) | 1 | |
| 4842103 | 10 CYLINDER GP-BUCKET (RH) | 1 | |
| 4848127 | 11 SPACER (35X90X3-MM THK) | 1 | |
| 4848135 | 12 COVER-CYLINDER (RH) | 1 | |
| 5093245 | 14 LINES GP-BUCKET TILT CYLINDER | 1 | |
| 4979729 | 16 COVER (LH) | 1 | |
| 7X2621 | 17 BOLT (M10X1.5X12-MM) | 2 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 19 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4222 | 20 WASHER-PLATED (11X32X2.5-MM THK) | 2 | |
| 8T4779 | 21 BOLT (M16X2X35-MM) | 2 | |
| 4820887 | 22 BUCKET AS-DITCH CLEANING | 1 | |
| 9R2821 | 23 BOSS (M10X1.5X15-MM) | 4 | |
| 1102961 | 24 BOSS (M6X1.0X16-MM) | 2 | |
| 4421812 | 25 EDGE | 1 | |
| 4827577 | 26 GUSSET (LH) | 1 | |
| 4827578 | 27 GUSSET (RH) | 1 | |
| 4848126 | 28 PLATE AS-HINGE | 1 | |
| 2C9259 | 29 PLATE-IDENTIFICATION (CAT) | 1 | |
| 4421795 | 30 PLATE (CORNER) | 2 |
