System And Components
509-9163 BUCKET GP-DITCH CLEANING1800-MM (72-IN) WIDE X 0.6-CU M (0.78-CU YD) CAPACITY
Group No: 509-9163
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8257 | 1 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 3B8489 | 2 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1598035 | 3 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 4 FILM-WARNING (READ OMM) | 1 | |
| 4841381 | 6 PIN AS | 1 | |
| 4841382 | 7 PIN AS | 2 | |
| 4841383 | 8 PIN GP-BUCKET | 1 | |
| 4842102 | 9 CYLINDER GP-BUCKET (LH) | 1 | |
| 4842103 | 10 CYLINDER GP-BUCKET (RH) | 1 | |
| 4848127 | 11 SPACER (35X90X3-MM THK) | 1 | |
| 5093245 | 13 LINES GP-BUCKET TILT CYLINDER (312-LINKAGE) | 1 | |
| 5099170 | 14 PIVOT AS | 1 | |
| 9R2672 | 14A BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 1788507 | 14B PLATE-WELD | 2 | |
| 4845091 | 14C BUSHING | 2 | |
| 7X2621 | 15 BOLT (M10X1.5X12-MM) | 2 | |
| 8T4222 | 16 WASHER-PLATED (11X32X2.5-MM THK) | 2 | |
| 8T4779 | 17 BOLT (M16X2X35-MM) | 2 | |
| 5099153 | 18 BUCKET AS-DITCH CLEANING | 1 | |
| 9R2672 | 19 BOSS-THREADED (M10X1.5X20-MM) | 2 | |
| 9R2821 | 20 BOSS (M10X1.5X15-MM) | 2 | |
| 4421847 | 21 EDGE | 1 | |
| 4827577 | 22 GUSSET (LH) | 1 | |
| 4827578 | 23 GUSSET (RH) | 1 | |
| 4421826 | 24 PLATE-WEAR | 2 | |
| 2C9259 | 25 PLATE-IDENTIFICATION (CAT) | 1 | |
| 4421795 | 26 PLATE (CORNER) | 2 | |
| 5099193 | 27 PLATE | 2 | |
| 4857928 | 29 PLATE-WEAR | 1 | |
| 5099277 | 30 BAR | 1 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 32 BOLT (M10X1.5X20-MM) | 4 | |
| 4848135 | 33 COVER-CYLINDER (RH) | 1 | |
| 4979729 | 34 COVER (LH) | 1 |
