482-0870 BUCKET GP-DITCH CLEANING -316-FAMILYS/N YDL1-UP
Group No: 482-0870 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8257 | 1 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 4959816 | 2 COVER-CYLINDER (LH) | 1 | |
| 1598035 | 3 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 4 FILM-WARNING (READ OMM) | 1 | |
| 4638184 | 5 COVER-CYLINDER (RH) | 1 | |
| 4663099 | 6 SPACER (35X90X6-MM THK) | 1 | |
| 4699342 | 7 CYLINDER GP-BUCKET (LH) | 1 | |
| 4699353 | 8 CYLINDER GP-BUCKET (RH) | 1 | |
| 4755000 | 9 PIN AS | 2 | |
| 4755002 | 10 PIN AS | 1 | |
| 4755004 | 11 PIN AS | 1 | |
| 4823804 | 12 PIVOT AS | 1 | |
| 4829099 | 12A BUSHING | 2 | |
| 9R2821 | 12B BOSS (M10X1.5X15-MM) | 7 | |
| 5093246 | 16 LINES GP-BUCKET TILT CYLINDER | 1 | |
| 7X2621 | 17 BOLT (M10X1.5X12-MM) | 3 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 19 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4222 | 20 WASHER-PLATED (11X32X2.5-MM THK) | 3 | |
| 8T4779 | 21 BOLT (M16X2X35-MM) | 2 | |
| 4900762 | 22 BUCKET AS-GENERAL PURPOSE | 1 | |
| 4428279 | 23 EDGE | 1 | |
| 4663078 | 24 PLATE AS-HINGE | 1 | |
| 2C9259 | 25 PLATE-IDENTIFICATION (CAT) | 1 | |
| 4428290 | 26 PLATE (CORNER) | 2 | |
| 4827577 | 27 GUSSET (LH) | 1 | |
| 4827578 | 28 GUSSET (RH) | 1 | |
| 1102961 | 29 BOSS (M6X1.0X16-MM) | 2 | |
| 9R2821 | 30 BOSS (M10X1.5X15-MM) | 4 |
