System And Components
372-7954 TORQUE CONVERTER ARS/N J2C1-225
Group No: 372-7954
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D4202 | 1 PLATE | 1 | |
| 2D6506 | 2 SEAL-O-RING | 1 | |
| 3E7434 | 3 COVER | 1 | |
| 9X2201 | 4 CLAMP-HOSE | 4 | |
| 4K1209 | 5 HOSE | 1 | |
| 5D4177 | 6 HOSE | 1 | |
| 8T4986 | 7 CLAMP-HOSE | 4 | |
| 5S7877 | 8 BALL BEARING | 2 | |
| 5S7878 | 9 RING-RETAINING | 2 | |
| 5T6942 | 10 CAP GP-PROTECTION (TRANSMISSION TANK) | 1 | |
| 6D7889 | 11 SEAL-O-RING | 1 | |
| 6E1528 | 12 PISTON | 1 | |
| 6V0852 | 14 CAP-DUST | 1 | |
| 7H1447 | 15 CAP-FILLER (HYDRAULIC OIL) | 1 | |
| 8C5172 | 16 SEAL-RECTANGULAR | 1 | |
| 8F9516 | 17 SEAL-O-RING | 1 | |
| 8T2275 | 18 BALL | 1 | |
| 9H6454 | 19 GASKET | 1 | |
| 9J3047 | 20 STRAINER (HYDRAULIC OIL) | 1 | |
| 1440367 | 21 CLAMP-HOSE | 4 | |
| 9M9545 | 22 SEAL-O-RING | 2 | |
| 9T7223 | 23 SPRING | 1 | |
| 1241858 | 24 SEAL-O-RING | 2 | |
| 1286488 | 25 HOSE AS | 1 | |
| 1407156 | 27 COVER | 1 | |
| 3697892 | 28 GEAR-RING (46-TEETH) | 1 | |
| 1436120 | 29 PLATE | 1 | |
| 1436121 | 30 RING | 1 | |
| 1464369 | 31 GEAR (127-TEETH) | 2 | |
| 1493985 | 32 VALVE GP-RELIEF (TORQUE CONVERTER OUTLET) | 1 | |
| 1493987 | 33 VALVE GP-RELIEF (TORQUE CONVERTER INLET) | 1 | |
| 1522708 | 34 COVER-TORQUE CONVERTER | 1 | |
| 1522709 | 35 TUBE AS-BAFFLE | 1 | |
| 1522716 | 36 GROMMET | 2 | |
| 1522717 | 37 GLASS | 2 | |
| 1522718 | 38 GASKET | 1 | |
| 1522725 | 39 SCREEN AS (BYPASS) | 2 | |
| 1522729 | 40 SLEEVE | 1 | |
| 1522730 | 41 SLEEVE | 1 | |
| 1532990 | 42 MANIFOLD | 1 | |
| 1539963 | 43 RING | 2 | |
| 1564268 | 44 MANIFOLD | 1 | |
| 4916720 | 45 COVER GP-TORQUE CONVERTER | 1 | |
| 1627788 | 46 PLATE-SERIAL NUMBER (TORQUE CONVERTER) | 1 | |
| 6V5845 | 48 BOLT (M20X2.5X70-MM) | 12 | |
| 1663445 | 49 MANIFOLD | 1 | |
| 3777063 | 51 SCREEN GP-MAGNETIC (TRANSMISSION OIL) | 1 | |
| 1864193 | 52 CLAMP AS | 2 | |
| 1937364 | 54 DRAIN AS | 2 | |
| 8C3080 | SEAL-O-RING | 1 | |
| 4186791 | 55 PLUG | 2 | |
| 2170729 | 57 COVER AS | 1 | |
| 2443712 | 59 PLUG AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 4193248 | 60 PLUG AS | 2 | |
| 4J5267 | SEAL-O-RING | 1 | |
| 2546118 | 61 CLAMP AS | 2 | |
| 4603011 | 62 YOKE | 1 | |
| 2579966 | 63 MANIFOLD | 1 | |
| 2579967 | 64 MANIFOLD | 1 | |
| 2579968 | 65 SLEEVE | 1 | |
| 2758880 | 66 FLANGE | 2 | |
| 2762955 | 67 PUMP GP-GEAR (XMSN CONTROL, CHARGE, SCAVENGE) | 1 | |
| 2762995 | 68 PUMP GP-GEAR (TC CHARGE, XMSN LUB) | 1 | |
| 2792252 | 69 SEAL-O-RING | 2 | |
| 2794594 | 70 TORQUE CONVERTER GP | 1 | |
| 2802086 | 71 HOUSING AS-TORQUE CONVERTER | 1 | |
| 1A5919 | DOWEL | 2 | |
| 2963232 | 73 MANIFOLD | 1 | |
| 2963234 | 74 MANIFOLD | 1 | |
| 3072671 | 75 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3149750 | 76 INDICATOR-LEVEL (TORQUE CONV OIL (LOW, HOT)) | 1 | |
| 3149751 | 77 INDICATOR-LEVEL (TORQUE CONV OIL (LOW, COLD)) | 1 | |
| 3218641 | 78 PLUG AS | 1 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 5080836 | 79 BRACKET-FILTER | 1 | |
| 3228293 | 80 TUBE AS | 1 | |
| 3228294 | 81 TUBE AS | 1 | |
| 3228295 | 82 TUBE AS | 1 | |
| 3228296 | 83 TUBE AS | 1 | |
| 3228297 | 84 TUBE AS | 1 | |
| 3228298 | 85 TUBE AS | 1 | |
| 3260318 | 86 PLUG AS | 3 | |
| 9S7583 | PLUG | 1 | |
| 2287097 | SEAL-O-RING | 1 | |
| 3260319 | 87 PLUG AS | 1 | |
| 9S4188 | PLUG | 1 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3260320 | 88 PLUG AS | 1 | |
| 5P7684 | PLUG | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3653179 | 89 SEAL-LIP TYPE | 1 | |
| 3693235 | 91 FILTER GP-OIL (XMSN, TORQUE CONVERTER CHARGE) | 1 | |
| 4254563 | 92 VALVE GP-MODULATING (TORQUE CONVERTER LOCKUP CLUTCH) | 1 | |
| 0329313 | 93 SEAL-O-RING | 1 | |
| 0336031 | 95 SEAL-O-RING | 6 | |
| 0619457 | 96 SEAL-O-RING | 3 | |
| 6V3303 | 97 BOLT (M16X2X60-MM) | 4 | |
| 1092332 | 98 SEAL-O-RING | 2 | |
| 1187536 | 99 SEAL-O-RING | 2 | |
| 1259794 | 100 SEAL-O-RING | 2 | |
| 1565782 | 101 SPACER (17.5X30X10-MM THK) | 4 | |
| 1729966 | 103 BOLT (M12X1.75X65-MM) | 6 | |
| 1984778 | 104 WASHER-HARD (13.5X30X12-MM THK) | 2 | |
| 1P7016 | 105 FLANGE-HALF | 4 | |
| 1541580 | 106 WASHER-HARD (22X38X6-MM THK) | 12 | |
| 2697885 | 107 SEAL-O-RING | 4 | |
| 2904542 | 108 FILLER | 1 | |
| 2H8050 | 109 RING-RETAINING | 2 | |
| 2M0849 | 110 WASHER-HARD (13.5X25.5X5-MM THK) | 6 | |
| 2Y5829 | 111 NUT (M10X1.5-THD) | 4 | |
| 3072670 | 112 PLUG AS | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3133492 | 113 PLUG AS | 3 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3196231 | 114 PLUG AS | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196234 | 115 PLUG AS | 2 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 2993424 | 116 WASHER-HARD (17.5X30X6-MM THK) | 84 | |
| 2048000 | 117 MOUNTING-CABLE TIE | 1 | |
| 5D5957 | 118 SEAL-O-RING | 1 | |
| 5P0840 | 119 SEAL-O-RING | 2 | |
| 5P5061 | 120 FLANGE-CAPTIVE | 2 | |
| 5P8245 | 121 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 5S9134 | 123 SEAL-O-RING | 2 | |
| 6V1197 | 124 SEAL-O-RING | 3 | |
| 6V1820 | 125 BOLT (M10X1.5X30-MM) | 12 | |
| 4920311 | 126 SEAL | 2 | |
| 8T4985 | 127 CLAMP-HOSE | 4 | |
| 6V3668 | 128 BOLT (M12X1.75X30-MM) | 6 | |
| 6V4248 | 129 BOLT (M10X1.5X25-MM) | 12 | |
| 6V5684 | 131 BOLT (M12X1.75X45-MM) | 12 | |
| 6V5686 | 132 BOLT (M16X2X50-MM) | 24 | |
| 6V5839 | 133 WASHER (11X21X2.5-MM THK) | 28 | |
| 6V5843 | 134 BOLT (M10X1.5X45-MM) | 4 | |
| 6V8001 | 136 SEAL-O-RING | 3 | |
| 6V8197 | 137 BOLT (M12X1.75X40-MM) | 6 | |
| 6V8336 | 139 BOLT (M12X1.75X70-MM) | 4 | |
| 6V8675 | 140 BOLT (M12X1.75X35-MM) | 4 | |
| 6V9607 | 141 BOLT (M8X1.25X120-MM) | 1 | |
| 7D7111 | 142 SEAL-O-RING | 1 | |
| 7X2554 | 143 BOLT (M16X2X70-MM) | 4 | |
| 8T0070 | 144 BOLT (M20X2.5X120-MM) | 1 | |
| 8T2393 | 145 BOLT-SOCKET HEAD (M16X2X60-MM) | 4 | |
| 8T4176 | 146 BOLT (M12X1.75X90-MM) | 16 | |
| 8T4121 | 147 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4140 | 149 BOLT (M16X2X60-MM) | 72 | |
| 8T4193 | 150 BOLT (M16X2X50-MM) | 4 | |
| 8T4223 | 151 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 9M1974 | 152 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X8268 | 153 WASHER (17.5X30X3.5-MM THK) | 24 | |
| 2042281 | 155 STRAP-CABLE | 1 | |
| 7X0457 | 156 BOLT (M8X1.25X130-MM) | 1 | |
| 4556751 | 157 FILM-IDENTIFICATION (FILTER) | 1 | |
| 5P8347 | 158 BOLT (M8X1.25X70-MM) | 2 | |
| 6V3822 | 159 BOLT (M10X1.5X35-MM) | 4 | |
| 3653180 | 160 SEAL-WEAR SLEEVE | 1 | |
| 6V7673 | 161 BOLT (M12X1.75X50-MM) | 2 | |
| 3310700 | 162 GROMMET | 1 | |
| 5080835 | 163 BRACKET-FILTER | 1 | |
| 6G0609 | 164 HOSE | 1 | |
| 1U8846 | SEALANT-GASKET |
