System And Components
Assembly
100%

426-1785 FRAME GP-UPPERS/N GMY1-UP

Group No: 426-1785
Part NumberPart NameQty
09300831 SHIM (1-MM THK)4
09301152 SHIM (2-MM THK)2
13324253 SHIM (0.5-MM THK)2
4I48124 PIN AS2
21228385 SHIM (2-MM THK)2
30887756 SHIM (0.5-MM THK)1
30887767 SHIM (1-MM THK)2
30887778 SHIM (2-MM THK)1
32409389 PLATE1
343929510 PIN AS1
426179311 FRAME AS-UPPER1
438009812 SHEET2
441733913 SHEET1
441734014 SHEET1
093034915 WASHER (22X60X6-MM THK)2
093036316 SPACER (83X120X12-MM THK)2
107220717 RIVET-POP28
7X255318 BOLT (M16X2X40-MM)2
8T412319 WASHER (22X35X3.5-MM THK)2
8T478020 BOLT (M20X2.5X30-MM)2
9X203821 WASHER (7X19X2-MM THK)28
9X825722 WASHER (17.5X30X3.5-MM THK)2
