Assembly
100%

336-1545 MOUNTING GP-AIR CLEANERAN ATTACHMENT

Group No: 336-1545
Part NumberPart NameQty
5N78221 AIR CLEANER GP2
5N79063 SUPPORT AS1
5N79084 BRACKET AS (RH)1
5N79105 BRACKET AS (LH)1
5N79166 BRACKET2
5N79177 SPACER (10.74X17.14X54.4-MM THK)2
5P48698 CLAMP-HOSE4
309185411 HOSE2
309459112 BRACKET1
087379614 SPACER (17.61X21.34X48-MM THK)2
0S158815 BOLT (3/8-16X1.25-IN)1
1A202916 BOLT (3/8-16X1.125-IN)4
3B191519 BOLT (3/8-16X1.375-IN)4
5M289420 WASHER-HARD (10.2X18.5X2.5-MM THK)12
5P824521 WASHER-HARD (13.5X25.5X3-MM THK)6
6H171723 BOLT (1/2-13X1.125-IN)6
8T250224 BOLT (3/8-16X1.125-IN)12
8T489625 WASHER-HARD (10.2X18.5X2.5-MM THK)16
8T891526 BOLT (3/8-16X3.25-IN)4
9S875227 NUT-FULL (3/8-16-THD)5
9X645828 WASHER-HARD (10.2X22.5X3-MM THK)2
8T489629 WASHER-HARD (10.2X18.5X2.5-MM THK)10
8N9729COVER-AIR CLEANER HOUSING2
7W5760FASTENER20
