System And Components
443-0642 LINES GP-TURBOCHARGER OILS/N N6R1-UP
Group No: 443-0642
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1665022 | 1 ELBOW | 2 | |
| 2841210 | 2 TUBE | 2 | |
| 3113212 | 3 TUBE AS | 2 | |
| 3188420 | 4 HOSE AS | 1 | |
| 3188421 | 5 HOSE AS | 1 | |
| 3535133 | 6 ELBOW AS | 2 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3537953 | 7 GROMMET | 5 | |
| 0S1588 | 8 BOLT (3/8-16X1.25-IN) | 5 | |
| 0S1590 | 9 BOLT (3/8-16X2-IN) | 1 | |
| 1003237 | 10 GROMMET | 6 | |
| 2B0941 | 11 SPACER (10.5X19X19-MM THK) | 1 | |
| 4B3388 | 12 BOLT (5/16-18X1.125-IN) | 4 | |
| 5P3456 | 13 SEAL-O-RING | 2 | |
| 6V5134 | 14 SEAL-O-RING | 4 | |
| 7S3916 | 15 CLIP (TAB) | 5 | |
| 7S3919 | 16 CLIP (SLOT) | 5 | |
| 7X0818 | 17 BOLT (M8X1.25X45-MM) | 4 | |
| 8C0624 | 18 SEAL-O-RING | 2 | |
| 8T1887 | 19 CLIP (SLOT) | 6 | |
| 8T1888 | 20 CLIP (TAB) | 6 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S8752 | 22 NUT-FULL (3/8-16-THD) | 6 | |
| 9X6458 | 23 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
