System And Components
Assembly
100%

157-3495 HOUSING GP-ENGINE BRAKEPART OF 148-7486, 157-3494 ENGINE BRAKE GP

Group No: 157-3495
Part NumberPart NameQty
14365801 PISTON2
2U14932 SEAL1
2U14923 SEAL1
14325364 SPRING (INNER)(CONTROL VALVE)2
14325965 SPRING (OUTER)(CONTROL VALVE)2
14365896 COVER2
14366797 RING-RETAINING2
1Q95518 SCREW-BUTTON HEAD (1/2-20X3/8-IN)2
14365819 SPRING (OUTER)(SLAVE PISTON)2
143658810 WASHER (12.7X36.1X1.07-MM THK)2
143656111 RING-RETAINING2
143659012 PUSHROD AS2
143658213 SPRING (INNER)(SLAVE PISTON)2
148748514 SCREW AS-ADJUSTMENT2
6B668415 NUT-FULL (1/2-20-THD)2
143657916 CLIP-HARNESS1
143658317 PISTON (MASTER)2
143658418 SPRING (MASTER PISTON)2
164202519 KIT-RETAINER (COMPRESSION BRAKE)2
143658520 PUSHROD (MASTER PISTON)2
102878021 SPOOL AS-VALVE2
163155322 SOLENOID (24-VOLT)(ENGINE BRAKE)1
143668023 SCREW-DRIVE1
143664224 SEAL1
