Assembly
100%

527-5369 RADIATOR GPS/N NGH1-UP

Group No: 527-5369
Part NumberPart NameQty
1P42781 CLAMP-HOSE1
8D09832 MOUNTING AS-VIBRATION ISOLATOR (HYDRAULIC TANK)4
9Y92363 GAUGE-SIGHT (COOLANT)2
03111194 CAP AS-RADIATOR1
34988065 PLATE2
35087606 SEAL1
52753707 CORE AS-AFTERCOOLER1
2253227FILM-WARNING (HOT SURFACE)1
2591127NUT-CLIP4
52753718 CORE AS-RADIATOR1
2253227FILM-WARNING (HOT SURFACE)1
2254256FILM-WARNING (HOT FLUID UNDER PRESSURE, U.S.)1
2591127NUT-CLIP4
34456759 NUT (M10X1.5-THD)4
7M848510 SEAL-O-RING2
8T413911 BOLT (M12X1.75X30-MM)4
8T422312 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422613 WASHER-PLATED (10.5X45X3-MM THK)8
8T646614 BOLT (M10X1.5X60-MM)4
224769715 HOSE (139-CM)
