System And Components
159-3545 LINES GP-WATER (CHG -01, -02, -02D1, -02D2)OUTLET CONTROL
Group No: 159-3545
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1625 | 1 BOLT (5/8-11X2.5-IN) | 8 | |
| 1D4608 | 2 BOLT (3/4-10X2.75-IN) | 8 | |
| 1S5772 | 3 GASKET | 5 | |
| 1W4152 | 4 RETAINER | 4 | |
| 4W7749 | 5 GASKET | 2 | |
| 6Y9542 | 6 CLAMP | 2 | |
| 8C6790 | 7 JOINT AS-PIPE | 1 | |
| 9X7539 | SEAL | 2 | |
| 8N8570 | 8 RING-RETAINING | 2 | |
| 9F8127 | 9 GASKET | 1 | |
| 1168654 | 10 CONNECTION-FLEXIBLE | 1 | |
| 1207521 | 11 ADAPTER AS | 1 | |
| 1588548 | 12 TEE AS | 1 | |
| 1588551 | 13 TEE AS | 1 | |
| 1588552 | 14 BRACKET AS | 1 | |
| 1588553 | 15 PIPE AS | 1 | |
| 7N7009 | FLANGE | 2 | |
| 1588554 | 16 FLANGE | 1 | |
| 1588557 | 17 BRACKET AS | 1 | |
| 1588558 | 18 PIPE AS | 1 | |
| 1588559 | 19 PIPE AS | 1 | |
| 1588560 | 20 ADAPTER AS | 2 | |
| 7N7009 | FLANGE | 1 | |
| 1630018 | 21 TUBE | 1 | |
| 0L1143 | 22 BOLT (3/8-16X2.5-IN) | 8 | |
| 0S1571 | 23 BOLT (3/8-16X1.75-IN) | 8 | |
| 0S1590 | 24 BOLT (3/8-16X2-IN) | 24 | |
| 0S1591 | 25 BOLT (3/8-16X1.5-IN) | 16 | |
| 0S1594 | 26 BOLT (3/8-16X1-IN) | 8 | |
| 1A8063 | 27 BOLT (3/4-10X2.5-IN) | 8 | |
| 2J3506 | 28 NUT-FULL (3/4-10-THD) | 16 | |
| 3D2824 | 29 SEAL-O-RING | 1 | |
| 3V3308 | 30 WASHER-HARD (10.2X20.5X2.5-MM THK) | 88 | |
| 4K0367 | 31 NUT-FULL (5/8-11-THD) | 8 | |
| 5P8247 | 32 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 5P8248 | 33 WASHER-HARD (20X36.5X3.5-MM THK) | 32 | |
| 8T2903 | 34 SEAL-O-RING | 2 | |
| 8T6760 | 35 PLUG-PIPE (1-1/2-11-1/2 NPT) | 1 | |
| 8T6762 | 36 PLUG-PIPE (1/2-14-THD) | 4 | |
| 9S4183 | 37 PLUG (1-1/16-12-THD) | 1 | |
| 9S8752 | 38 NUT-FULL (3/8-16-THD) | 16 | |
| 0S1588 | 39 BOLT (3/8-16X1.25-IN) | 8 | |
| 3B1915 | 40 BOLT (3/8-16X1.375-IN) | 16 |
