System And Components
129-2892 AIR COMPRESSOR GPS/N 8YS3534-UP
Group No: 129-2892
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W5499 | 1 ELBOW | 1 | |
| 8M7065 | 2 GASKET (AIR INLET) | 1 | |
| 9M2904 | 3 CLAMP-HOSE | 1 | |
| 0323631 | 4 ELBOW | 1 | |
| 0908635 | 5 SPACER (11X22X5-MM THK) | 1 | |
| 1260146 | 6 HOSE-FUMES DISPOSAL | 1 | |
| 1280331 | 7 HOSE | 1 | |
| 1292181 | 8 SEAL-INTEGRAL | 1 | |
| 1312171 | 9 CONNECTOR | 1 | |
| 1537062 | 10 BRACKET | 1 | |
| 1666352 | 11 TUBE AS | 1 | |
| 1724702 | 12 CLAMP | 2 | |
| 0017043 | 13 ELBOW | 1 | |
| 0050658 | 14 ELBOW-FLARED | 1 | |
| 0307946 | 15 ELBOW | 1 | |
| 1184728 | 16 ELBOW | 1 | |
| 0307949 | 17 ELBOW | 1 | |
| 1170221 | 18 RING-PILOT | 1 | |
| 1280420 | 19 GEAR (42-TEETH) | 1 | |
| 1292890 | 20 HOSE AS | 1 | |
| 1292891 | 21 HOSE AS | 1 | |
| 1647564 | 22 AIR COMPRESSOR GP | 1 | |
| 2B2695 | 23 BOLT (5/16-18X0.875-IN) | 2 | |
| 2S2053 | 24 CLIP (LOOP) | 1 | |
| 3E4353 | 25 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 5S0003 | 27 NUT (5/16-18-THD) | 2 | |
| 6V3251 | 28 SEAL-O-RING | 2 | |
| 6V4248 | 29 BOLT (M10X1.5X25-MM) | 3 | |
| 6V5048 | 30 SEAL-O-RING | 1 | |
| 6V5063 | 31 SEAL-O-RING | 1 | |
| 6V5839 | 32 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V6609 | 33 SEAL-O-RING | 1 | |
| 6V7742 | 34 NUT-FULL (M20X2.5-THD) | 1 | |
| 6V8197 | 35 BOLT (M12X1.75X40-MM) | 3 | |
| 8L6557 | 36 CONNECTOR | 1 | |
| 8M2770 | 37 CLIP (LOOP) | 1 | |
| 8T3282 | 38 WASHER-HARD (22X35X3.5-MM THK) | 1 | |
| 9M1974 | 39 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9M8406 | 40 CLIP (LOOP) | 1 | |
| 9N0869 | 41 WASHER-HARD (8.8X25.5X2-MM THK) | 2 |
