System And Components
136-4282 BELT TENSIONER GPINCLUDES ALTERNATOR BRACKET, POSITIONING STRAP, AND 240 IN/LB BELT TIGHTENER
Group No: 136-4282
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1337040 | 1 BRACKET | 1 | |
| 1337042 | 2 BRACKET | 1 | |
| 1333544 | 3 BELT TENSIONER | 1 | |
| 6V5839 | 4 WASHER (11X21X2.5-MM THK) | 1 | |
| 9H8260 | 5 BOLT (1/2-13X6.25-IN) | 1 | |
| 1F7958 | 6 NUT-FULL (1/2-13-THD) | 1 | |
| 5P8245 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V1820 | 8 BOLT (M10X1.5X30-MM) | 5 | |
| 3E4353 | 9 WASHER-HARD (11X25X3-MM THK) | 5 | |
| 8T0643 | 10 BOLT (M10X1.5X80-MM) | 5 | |
| 0S1595 | 11 BOLT (1/2-13X1.25-IN) | 1 | |
| 1316655 | 12 STRAP | 1 | |
| 7D1649 | 13 WASHER-HARD (13.5X32X5-MM THK) | 1 | |
| 6V8197 | 14 BOLT (M12X1.75X40-MM) | 1 | |
| 6V8149 | 15 NUT (M12X1.75-THD) | 1 |
