System And Components
179-7803 LINES GP-PILOT -CONTROL VALVE, PUMPS/N DAA1-189; FED1-322
Group No: 179-7803
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1488364 | 1 ELBOW AS | 5 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | 2 SEAL-O-RING | 1 | |
| 1087354 | 3 HOSE AS | 1 | |
| 1488353 | 4 ELBOW AS | 7 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 3J1907 | 5 SEAL-O-RING | 1 | |
| 6V8397 | 6 SEAL-O-RING | 5 | |
| 1488378 | 7 ELBOW AS | 12 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488407 | 8 PLUG AS | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488336 | 9 CONNECTOR AS | 10 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488340 | 10 CONNECTOR AS | 5 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488433 | 11 TEE AS | 3 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1645608 | 12 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T1687 | CONNECTOR | 1 | |
| 1488435 | 13 TEE AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1488358 | 14 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8624 | ELBOW | 1 | |
| 3D2824 | 15 SEAL-O-RING | 1 | |
| 6V9746 | 16 SEAL-O-RING | 1 | |
| 1536237 | 17 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1689759 | 18 BLOCK | 1 | |
| 1488439 | 19 TEE AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 1488327 | 20 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1646872 | 21 TEE AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1158634 | TEE-O-RING | 1 | |
| 4I6121 | 22 HOSE AS | 1 | |
| 1488354 | 23 ELBOW AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1940079 | 24 FITTING | 1 | |
| 1488338 | 25 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T0075 | CONNECTOR | 1 | |
| 1488347 | 26 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1764770 | 27 HOSE AS | 1 | |
| 2144512 | 28 FITTING GP-HYDRAULIC | 1 | |
| 1734675 | 29 HOSE AS | 1 | |
| 1136688 | 30 HOSE AS | 1 | |
| 1053484 | 31 BOLT-SOCKET HEAD (M10X1.5X25-MM) | 2 | |
| 1645567 | 32 COUPLER AS-QUICK DISCONNECT (MALE) | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1031384 | 33 GUARD | 1 | |
| 8T4198 | 34 BOLT (M10X1.5X100-MM) | 2 | |
| 1991777 | 35 HOSE AS | 1 | |
| 0875783 | 36 HOSE AS | 1 | |
| 1764768 | 37 HOSE AS | 1 | |
| 1849147 | 38 HOSE AS | 1 | |
| 2076641 | 39 HOSE AS | 1 | |
| 7Y4199 | 40 HOSE AS | 1 | |
| 1289166 | 41 HOSE AS | 1 | |
| 1504044 | 42 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1779 | CONNECTOR | 1 | |
| 1849593 | 43 HOSE AS | 1 | |
| 7K1181 | 44 STRAP-CABLE | 22 | |
| 1488374 | 45 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 8T4121 | 46 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 4I1739 | 47 HOSE AS | 1 | |
| 0874531 | 48 HOSE AS | 2 | |
| 1087363 | 49 HOSE AS | 1 | |
| 6D1641 | 50 CLIP (LOOP) | 3 | |
| 8T4191 | 51 BOLT (M10X1.5X16-MM) | 1 | |
| 2218859 | 52 SENSOR AS-PRESSURE (MAIN PUMP) | 2 | |
| 1710596 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 0875760 | 53 HOSE AS | 1 | |
| 5I8708 | 54 HOSE AS | 1 | |
| 1105496 | 55 HOSE AS | 1 | |
| 6V0852 | 56 CAP-DUST | 6 | |
| 1488371 | 57 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 8T4139 | 58 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4223 | 59 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 2024004 | 60 GROMMET | 1 | |
| 2023931 | 61 HOSE AS | 1 | |
| 1764469 | 62 BLOCK | 1 | |
| 0874456 | 63 ACCUMULATOR GP-HYDRAULIC (CHARGED) | 1 | |
| 5P7464 | 64 CLIP (SLOT) | 1 | |
| 5P7465 | 65 CLIP (TAB) | 1 | |
| 6V7359 | 66 GROMMET (25-MM ID, 37-MM OD) | 1 | |
| 1048838 | 67 HOSE AS | 1 | |
| 1764472 | 68 HOSE AS | 1 | |
| 2155037 | 69 MANIFOLD GP-CONTROL (PILOT OIL SUPPLY) | 1 | |
| 1764463 | 70 PLATE | 1 | |
| 1232430 | 71 VALVE GP-SHUTTLE | 1 | |
| 0993649 | 72 BOLT (M8X1.25X40-MM) | 2 | |
| 2324102 | 73 VALVE GP-PRESSURE REDUCING (BOOM, SWING PRIORITY) | 1 | |
| 8T4172 | 74 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4192 | 75 BOLT (M12X1.75X25-MM) | 3 | |
| 4I0836 | 76 HOSE AS | 1 | |
| 0875774 | 77 HOSE AS | 1 | |
| 0874534 | 78 HOSE AS | 1 | |
| 1434254 | 79 HOSE AS | 1 | |
| 2180998 | 80 HOSE AS | 1 | |
| 1648977 | 81 HOSE AS | 1 | |
| 1335733 | 82 HOSE AS | 1 | |
| 5I4396 | 83 HOSE AS | 1 | |
| 5I4371 | 84 STOPPER | 1 | |
| 1849595 | 85 HOSE AS | 1 | |
| 1021157 | 86 HOSE AS | 1 | |
| 0874411 | 87 HOSE AS | 1 | |
| 0875772 | 88 HOSE AS | 1 | |
| 1648983 | 89 HOSE AS | 1 | |
| 0875762 | 90 HOSE AS | 1 | |
| 4I0797 | 91 HOSE AS | 1 | |
| 1391759 | 92 HOSE AS | 1 | |
| 0875776 | 93 HOSE AS | 1 | |
| 1764569 | 94 HOSE AS | 1 | |
| 6D4246 | 95 CLIP (LOOP) | 1 | |
| 4I9527 | 96 BAND-MARKER (GREEN, R3) | 6 | |
| 4I9528 | 97 BAND-MARKER (PURPLE, R4) | 4 | |
| 4I9521 | 98 BAND-MARKER (RED, L1) | 2 | |
| 4I9524 | 99 BAND-MARKER (BROWN, L4) | 2 | |
| 4I9523 | 100 BAND-MARKER (BLUE, L3) | 4 | |
| 4I9522 | 101 BAND-MARKER (YELLOW, L2) | 4 | |
| 4I9525 | 102 BAND-MARKER (ORANGE, R1) | 2 | |
| 8T4137 | 103 BOLT (M10X1.5X20-MM) | 6 | |
| 4I5906 | 104 HOSE AS | 1 | |
| 7Y8379 | 105 HOSE AS | 1 | |
| 1875681 | 106 HOSE AS | 1 | |
| 4I0818 | 107 HOSE AS | 1 | |
| 4I7889 | 108 SPACER (11X25X45-MM THK) | 1 | |
| 1488365 | 109 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 8T5005 | 110 BOLT (M10X1.5X70-MM) | 1 | |
| 1488436 | 111 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8775 | TEE-FACE SEAL | 1 | |
| 4I9526 | 112 BAND-MARKER (WHITE, R2) | 2 | |
| 6V8398 | 113 SEAL-O-RING | 1 | |
| 1503036 | 114 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1360207 | 115 STRAP-CABLE (BLACK) | 3 | |
| 4K8864 | 116 CLIP (LOOP) | 1 | |
| 6D4244 | 117 CLIP (LOOP) | 1 | |
| 8T2920 | 118 GROMMET (27-MM ID) | 1 | |
| 8T4133 | 119 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 120 BOLT (M10X1.5X25-MM) | 1 | |
| 1488367 | 121 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 7C4354 | 122 CLIP | 1 |
