System And Components
291-0403 LINES GP-BOOM CYLINDER -VARIABLE ADJUSTABLES/N WBJ1-UP; ZGZ1-UP
Group No: 291-0403
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1786866 | 1 SPACER | 1 | |
| 2064917 | 2 ELBOW | 1 | |
| 3170914 | 3 VALVE GP-CHECK & RELIEF (STICK LOWERING) | 1 | |
| 2330300 | 4 BLOCK-HYDRAULIC | 1 | |
| 2692508 | 5 HOSE AS | 1 | |
| 3274181 | 6 PLATE | 1 | |
| 2910404 | 7 HOSE AS | 1 | |
| 0919035 | 8 SPACER (11X25X20-MM THK) | 1 | |
| 1081781 | 9 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 4 | |
| 1488455 | 11 UNION AS | 2 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1P3703 | 12 SEAL-RECTANGULAR | 1 | |
| 1P3704 | 13 SEAL-RECTANGULAR | 1 | |
| 2M9780 | 14 SEAL-O-RING | 1 | |
| 2P1293 | 15 LOCKNUT (1-3/16-12-THD) | 2 | |
| 4J5267 | 16 SEAL-O-RING | 2 | |
| 5P7466 | 17 CLIP (SLOT) | 1 | |
| 5P7467 | 18 CLIP (TAB) | 1 | |
| 5P8112 | 19 GROMMET | 1 | |
| 6V0400 | 20 FLANGE-HALF | 2 | |
| 6V9746 | 21 SEAL-O-RING | 1 | |
| 1053479 | 22 BOLT-SOCKET HEAD (M10X1.5X90-MM) | 4 | |
| 8T4185 | 24 BOLT (M10X1.5X50-MM) | 5 | |
| 8T4194 | 25 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4910 | 28 BOLT (M12X1.75X60-MM) | 2 | |
| 9S4190 | 29 PLUG-O-RING (7/8-14-THD) | 1 |
