System And Components
7R-9158 TRACK GP -LHS/N 3TK74-107
Group No: 7R-9158
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7R9157 | 1 FRAME AS-TRACK | 1 | |
| 1140893 | 2 PLANETARY GP-FINAL DRIVE | 1 | |
| 2J0564 | 3 LOCKNUT (2-12-THD) | 2 | |
| 3G9303 | 4 PIN | 2 | |
| 1S9292 | 5 DOWEL | 2 | |
| 0871764 | 6 SHAFT | 2 | |
| 7R9160 | 7 IDLER GP-TRACK | 1 | |
| 0870240 | 8 TRACK ADJUSTER & RECOIL GP | 1 | |
| 1G6133 | 9 SPROCKET-TRACK | 1 | |
| 7G4831 | 10 CAP GP-TRACK ROLLER | 8 | |
| 7G4836 | 11 ROLLER GP-TRACK-SINGLE FLANGE | 4 | |
| 1061832 | 12 TRACK GP | 1 | |
| 7X0515 | 13 WASHER-HARD (17X35X5-MM THK) | 35 | |
| 8T4140 | 14 BOLT (M16X2X60-MM) | 18 | |
| 8T7338 | 15 BOLT (M16X2X45-MM) | 17 | |
| 1059636 | 16 ADAPTER | 1 | |
| 8F8733 | 17 SEAL-O-RING | 1 | |
| 8C6789 | 18 SCREW-HEX SOCKET | 2 |
