System And Components
229-6171 PAN GP-OIL -ENGINECENTER SUMP CONFIGURATION WITH SHALLOW SUMP OIL PAN
Group No: 229-6171
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6451 | 1 PLUG-DRAIN (MAGNETIC)(ENGINE OIL PAN) | 4 | |
| 2173673 | 2 SEAL-ISOLATION | 1 | |
| 2173674 | 3 FASTENER AS | 14 | |
| 2296200 | 4 BELL AS | 1 | |
| 2101743 | 4A ELBOW | 1 | |
| 2297252 | 5 PAN-OIL | 1 | |
| 0619458 | 6 SEAL-O-RING | 4 | |
| 3E8016 | 7 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 2 | |
| 5P8211 | 9 SEAL-O-RING | 1 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6A5591 | 11 BOLT (M12X1.75X25-MM) | 4 | |
| 6N8863 | 12 WASHER (10.2X32X2.5-MM THK) | 14 | |
| 6V4249 | 13 BOLT (M10X1.5X50-MM) | 13 | |
| 9M1974 | 14 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 3196234 | 15 PLUG AS | 2 | |
| 9S9334 | 15A PLUG (1-5/16-12-THD) | 1 | |
| 2385084 | 15B SEAL-O-RING | 1 | |
| 2873049 | 16 STUD (M10X1.5X50-MM) | 1 |
