System And Components
262-1010 SPEEDOMETER GPS/N C7F1-241; P7F1-127
Group No: 262-1010
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1302793 | 1 GROMMET | 1 | |
| 2143437 | 2 NUT (M18X1.5-THD) | 1 | |
| 2143438 | 3 SENSOR-SPEED | 1 | |
| 2144603 | 4 SUPPORT AS | 1 | |
| 2147861 | 5 SPEEDOMETER AS | 1 | |
| 4B2043 | NUT (8-32-THD) | 2 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9B7233 | LOCKWASHER | 2 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 2310748 | 6 SPACER | 1 | |
| 2899933 | 7 HARNESS AS-SENSOR (SPEED) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 2976900 | 8 HARNESS AS-SENSOR (SPEEDOMETER, TACHOMETER) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 3 | |
| 5P2321 | TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW) | 3 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 2976901 | 9 HARNESS AS-SWITCH (VIBRATORY) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 12 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 12 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 1907614 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 14 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 0950924 | 10 RING-RETAINING | 1 | |
| 5C2890 | 11 NUT (M6X1-THD) | 3 | |
| 7K1181 | 12 STRAP-CABLE | 5 | |
| 8T4138 | 13 BOLT (M6X1X20-MM) | 3 | |
| 9X8256 | 14 WASHER (6.6X12X2-MM THK) | 3 |
