System And Components
Assembly
100%

393-6476 ROPS GPS/N WRE1-UP; WDZ1-UP

Group No: 393-6476
Part NumberPart NameQty
6V39281 PLUG-BUTTON1
39140672 PLATE AS1
6V9632NUT-WELD (M6X1-THD)5
39140693 PLATE1
39364864 PLATE1
42086725 ROPS AS1
42590506 COVER AS1
6V9632NUT-WELD (M6X1-THD)1
45511797 INSERT-THREADED (M12X1.75-THD)8
45975338 INSERT-THREADED (M10X1.5-THD)24
3E43049 INSERT-THREADED (M6X1-THD)2
8T412310 WASHER (22X35X3.5-MM THK)5
8T497011 BOLT (M6X1X14-MM)4
8T546012 BOLT (M20X2.5X40-MM)5
9X203813 WASHER (7X19X2-MM THK)4
9X204214 SCREW-TRUSS HEAD (M6X1X12-MM)4
9X204415 SCREW-TRUSS HEAD (M6X1X16-MM)4
9X204516 SCREW-TRUSS HEAD (M6X1X20-MM)3
7X787717 STRIP-EDGE (6-CM)
7X787717A STRIP-EDGE (14-CM)
