197-3086 CONNECTION GP-GENERATOR LEADS -NEUTRALS/N SPY1-UP

Group No: 197-3086
Part NumberPart NameQty
16902991 CABLE AS (GROUND)3
5P2600RING-TERMINAL (000-GA, 1/2-IN SCREW)2
1883111CABLE (000-GA, GREEN, YELLOW STRIPE)(183-CM)
8T41372 BOLT (M10X1.5X20-MM)1
16902113 BAR3
8T41334 NUT (M10X1.5-THD)10
8T41215 WASHER-HARD (11X21X2.5-MM THK)26
8T64666 BOLT (M10X1.5X60-MM)7
14350997 INSULATOR2
7X26218 BOLT (M10X1.5X12-MM)2
8T41869 BOLT (M10X1.5X40-MM)5
7K118110 STRAP-CABLE3
6K080611 STRAP-CABLE9
7H821312 MAT3
9B723713 BOLT (3/8-16X1.25-IN)1
