System And Components
202-7401 CONNECTION GP-GENERATOR LEADSS/N SPY1-UP
Group No: 202-7401
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1690299 | 1 CABLE AS | 8 | |
| 5P2600 | RING-TERMINAL (000-GA, 1/2-IN SCREW) | 2 | |
| 1883111 | CABLE (000-GA, GREEN, YELLOW STRIPE)(183-CM) | ||
| 1690300 | 2 CABLE AS | 4 | |
| 5P2600 | RING-TERMINAL (000-GA, 1/2-IN SCREW) | 2 | |
| 1883111 | CABLE (000-GA, GREEN, YELLOW STRIPE)(98-CM) | ||
| 1690211 | 3 BAR | 3 | |
| 8T4133 | 4 NUT (M10X1.5-THD) | 10 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 26 | |
| 8T6466 | 6 BOLT (M10X1.5X60-MM) | 7 | |
| 1435099 | 7 INSULATOR | 2 | |
| 7X2621 | 8 BOLT (M10X1.5X12-MM) | 2 | |
| 8T4186 | 9 BOLT (M10X1.5X40-MM) | 5 | |
| 7K1181 | 10 STRAP-CABLE | 13 | |
| 6K0806 | 11 STRAP-CABLE | 9 | |
| 7H8213 | 12 MAT | 3 | |
| 9B7237 | 13 BOLT (3/8-16X1.25-IN) | 1 | |
| 8T4137 | 14 BOLT (M10X1.5X20-MM) | 1 |
