System And Components
438-3706 MOUNTING GP-ENGINE OIL FILTERSERVICE, LH
Group No: 438-3706
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1013121 | 1 SPACER (10.5X25X25-MM THK) | 1 | |
| 3722715 | 2 BRACKET AS | 1 | |
| 5251830 | 3 HOSE AS | 1 | |
| 3722718 | 4 HOSE AS | 1 | |
| 0919035 | 5 SPACER (11X25X20-MM THK) | 1 | |
| 1030892 | 6 GROMMET | 1 | |
| 1984778 | 7 WASHER-HARD (13.5X30X12-MM THK) | 8 | |
| 1P7009 | 8 CLIP | 1 | |
| 2270059 | 9 ELBOW | 1 | |
| 2154639 | 10 SEAL-O-RING | 1 | |
| 2877301 | 11 VALVE-BALL | 1 | |
| 2Y5829 | 12 NUT (M10X1.5-THD) | 2 | |
| 4J0527 | 13 SEAL-O-RING | 1 | |
| 5P8245 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 6V3823 | 15 BOLT (M12X1.75X60-MM) | 4 | |
| 6V5230 | 16 BOLT (M10X1.5X60-MM) | 2 | |
| 6V5839 | 17 WASHER (11X21X2.5-MM THK) | 4 | |
| 6V6782 | 18 CLIP (SLOT) | 1 | |
| 6V6783 | 19 CLIP (TAB) | 1 | |
| 6V7673 | 20 BOLT (M12X1.75X50-MM) | 4 | |
| 6V8149 | 21 NUT (M12X1.75-THD) | 8 | |
| 6V9008 | 22 ELBOW | 1 | |
| 7M8485 | 23 SEAL-O-RING | 2 | |
| 8T1897 | 24 CLIP (SLOT) | 1 | |
| 8T1898 | 25 CLIP (TAB) | 1 | |
| 2287093 | 26 SEAL-O-RING | 2 |
