System And Components
330-2533 LINES GP-PUMP -MEDIUM PRESSURES/N RBF1-UP
Group No: 330-2533 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T5005 | 1 BOLT (M10X1.5X70-MM) | 4 | |
| 6V0852 | 2 CAP-DUST | 1 | |
| 7K1181 | 3 STRAP-CABLE | 4 | |
| 2284710 | 4 SPACER (13.8X30X20-MM THK) | 1 | |
| 3661062 | 5 HOSE AS | 1 | |
| 3463390 | 6 FLANGE | 1 | |
| 2895700 | 7 GROMMET | 1 | |
| 2965750 | 8 CONNECTOR AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1095821 | CONNECTOR | 1 | |
| 3100165 | 9 VALVE GP-CONTROL (MEDIUM PRESSURE, PUMP RELIEF) | 1 | |
| 3337110 | 10 SUPPORT AS | 1 | |
| 3337149 | 11 HOSE AS | 1 | |
| 3372700 | 12 HOSE AS | 1 | |
| 3507362 | 13 SUPPORT AS | 1 | |
| 3507366 | 14 GROMMET | 1 | |
| 3660797 | 15 SUPPORT | 1 | |
| 3660837 | 16 SUPPORT AS | 1 | |
| 1488340 | 17 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488347 | 18 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 2967058 | 19 ELBOW AS | 1 | |
| 1950036 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1645567 | 20 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1648908 | 21 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T0077 | CONNECTOR | 1 | |
| 1654927 | 22 CONNECTOR AS | 1 | |
| 2T2991 | CONNECTOR | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1P4578 | 23 FLANGE-HALF | 2 | |
| 4J0522 | 24 SEAL-O-RING | 3 | |
| 5P7466 | 26 CLIP (SLOT) | 1 | |
| 5P7467 | 27 CLIP (TAB) | 1 | |
| 5P7468 | 28 CLIP (SLOT) | 3 | |
| 5P7469 | 29 CLIP (TAB) | 3 | |
| 5P8112 | 30 GROMMET | 1 | |
| 6V1874 | 31 GROMMET (31-MM ID) | 3 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4178 | 34 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4183 | 35 BOLT (M12X1.75X40-MM) | 3 | |
| 8T4184 | 36 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4192 | 37 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4196 | 38 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 15 | |
| 8T4910 | 40 BOLT (M12X1.75X60-MM) | 1 | |
| 8T4956 | 41 BOLT (M12X1.75X35-MM) | 6 |
