Assembly
100%

375-7961 COOLER GP-FUELS/N BDN1-UP

Group No: 375-7961
Part NumberPart NameQty
4P72331 GROMMET1
33433252 CORE AS-FUEL COOLER1
35087643 BRACKET AS2
35351344 ELBOW AS1
1184728ELBOW1
2385080SEAL-O-RING1
37948045 HOSE AS1
37796406 ELBOW AS1
0054173ELBOW1
2385081SEAL-O-RING1
24929438 STUD (3/8-16-THD)2
353795310 GROMMET2
5P107511 WASHER-HARD (10.2X22.5X3-MM THK)4
6V678212 CLIP (SLOT)2
6V678313 CLIP (TAB)2
6V880114 NUT (3/8-16-THD)5
8T188716 CLIP (SLOT)1
8T188817 CLIP (TAB)1
8T188918 CLIP (SLOT)2
8T189019 CLIP (TAB)2
8T412120 WASHER-HARD (11X21X2.5-MM THK)8
8T413721 BOLT (M10X1.5X20-MM)8
8T422222 WASHER-PLATED (11X32X2.5-MM THK)4
