System And Components
418-8812 CYLINDER & SEAL GP-BOOMS/N DTG1-UP
Group No: 418-8812
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4560195 | 1 SEAL-LIP TYPE | 1 | |
| 1211372 | 2 RING-BACKUP | 1 | |
| 1211371 | 3 SEAL-U-CUP | 1 | |
| 2043623 | 4 SEAL-BUFFER | 1 | |
| 0965625 | 5 BUSHING | 1 | |
| 0941931 | 6 RING-RETAINING | 1 | |
| 4229147 | 7 HEAD | 1 | |
| 4I3628 | 8 BOLT-SOCKET HEAD (M18X2.5X80-MM) | 12 | |
| 2667968 | 9 SEAL-O-RING | 1 | |
| 4I3627 | 10 RING-BACKUP | 1 | |
| 3509338 | 11 CYLINDER AS-BOOM | 1 | |
| 2285617 | 11A BUSHING | 1 | |
| 3509343 | 12 ROD AS | 1 | |
| 2909181 | 12A BUSHING | 1 | |
| 4I8869 | 13 STOP | 1 | |
| 1261876 | 14 RING-SEAL | 1 | |
| 4I3631 | 15 RING-BACKUP | 2 | |
| 0961570 | 16 SEAL AS | 1 | |
| 2478874 | 17 RING | 2 | |
| 0961571 | 18 RING | 2 | |
| 2478873 | 19 PISTON | 1 | |
| 0966210 | 20 SETSCREW-SOCKET (M14X2X14-MM) | 1 | |
| 4B9880 | 21 BALL | 1 | |
| 1661495 | 22 SEAL-LIP TYPE | 2 | |
| 9X4597 | 23 SEAL-LIP TYPE | 2 | |
| 3B8489 | 24 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 4642937 | KIT-SEAL (BOOM CYLINDER) | 1 |
