System And Components
535-7485 BUCKET AS-EXTREME SERVICE ROCK -DB-FAMILYS/N EBJ1-UP
Group No: 535-7485
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1386529 | 1 SHROUD (HEEL, STRAIGHT) | 2 | |
| 1386551 | 2 SHROUD (HEEL, CURVED) | 6 | |
| 5585895 | 3 PLATE | 1 | |
| 3324853 | 4 PLATE AS-HINGE | 1 | |
| 2623817 | 4A BOSS (M24X3X53-MM) | 1 | |
| 2623818 | 4B BOSS (M20X2.5X49-MM) | 1 | |
| 3483123 | 5 PLATE-WEAR | 1 | |
| 5331195 | 6 EDGE AS | 1 | |
| 5054160 | 6A ADAPTER-TIP (110, 2-STRAP, CENTER) | 3 | |
| 5054161 | 6B ADAPTER-TIP (110, 2-STRAP, RH) | 1 | |
| 5054162 | 6C ADAPTER-TIP (110, 2-STRAP, LH) | 1 | |
| 8P9770 | 6D PLATE | 1 | |
| 3655747 | 7 PLATE-WEAR | 1 | |
| 3655746 | 8 PLATE-WEAR | 4 | |
| 2C9259 | 9 PLATE-IDENTIFICATION (CAT) | 2 | |
| 3302174 | 10 BLOCK-SHEAR | 8 | |
| 3483250 | 11 PLATE-WEAR | 2 | |
| 5246475 | 12 PLATE-WEAR | 2 | |
| 3655751 | 13 PLATE (LH) | 1 | |
| 3655752 | 14 PLATE (RH) | 1 |
