System And Components
490-2770 SENSOR & MTG GP-POSITION -BUCKETS/N BR91-UP
Group No: 490-2770
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 18 | |
| 4784872 | 2 TARGET (SENSOR) | 1 | |
| 4784875 | 3 SENSOR GP-POSITION (DRILL ROTATION) | 1 | |
| 2304014 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 5834240 | 4 COVER AS | 1 | |
| 7T1099 | LINK | 2 | |
| 2954155 | 5 BOLT-SOCKET HEAD (M5X0.8X35-MM) | 4 | |
| 8T0328 | 6 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 8 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4138 | 9 BOLT (M6X1X20-MM) | 2 | |
| 8T4196 | 10 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4222 | 11 WASHER-PLATED (11X32X2.5-MM THK) | 4 | |
| 9X8256 | 12 WASHER (6.6X12X2-MM THK) | 2 | |
| 3E6600 | 13 SEAL (1.5-CM EACH) | ||
| 8T7934 | 14 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 5754554 | 15 PLATE | 3 |
