System And Components
575-2090 WIRING GP-CHASSISS/N BR920001-UP
Group No: 575-2090
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4196 | 1 BOLT (M10X1.5X35-MM) | 1 | |
| 2042281 | 2 STRAP-CABLE | 2 | |
| 8T4172 | 3 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4198 | 4 BOLT (M10X1.5X100-MM) | 1 | |
| 3S2093 | 5 STRAP-CABLE | 22 | |
| 5F9757 | 6 GROMMET | 1 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 39 | |
| 8T4136 | 8 BOLT (M10X1.5X25-MM) | 6 | |
| 9X2042 | 9 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 2024004 | 10 GROMMET | 1 | |
| 2041611 | 11 STRAP-CABLE (DUAL) | 1 | |
| 3432410 | 12 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4837805 | 13 SPACER (11X20X65-MM THK) | 1 | |
| 4837806 | 14 SPACER (11X20X56-MM THK) | 1 | |
| 4841451 | 15 CLIP | 20 | |
| 4841452 | 16 CLIP | 2 | |
| 4841453 | 17 CLIP (RETAINER) | 8 | |
| 4841454 | 18 CLIP-RETAINING | 7 | |
| 4841456 | 19 STRAP-CABLE | 45 | |
| 4906965 | 20 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4908083 | 21 PANEL GP-SWITCH (DISCONNECT) | 1 | |
| 5080558 | 22 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 5244506 | 23 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2667379 | 24 STRAP-CABLE | 3 | |
| 5429618 | 25 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5501970 | 26 HARNESS AS-SENSOR (AIR CLEANER) | 1 | |
| 5581494 | 27 HARNESS AS-CHASSIS (FUEL FILTER) | 1 | |
| 5766849 | 28 HARNESS AS-CAB (PRODUCT LINK 243, 083)(PRODUCT LINK 243, 083) | 1 | |
| 5766917 | 29 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 5767937 | 30 HARNESS AS-CHASSIS | 1 | |
| 7K1181 | 31 STRAP-CABLE | 13 | |
| 8T4137 | 32 BOLT (M10X1.5X20-MM) | 30 | |
| 9R7941 | 33 SOCKET AS | 1 | |
| 9R7980 | COVER | 1 |
