570-4688 LINES GP-AUXILIARY HYDRAULIC -HIGH PRESSURE, REACH BOOMS/N BR61-UP

Group No: 570-4688
Part NumberPart NameQty
1P37041 SEAL-RECTANGULAR2
8T41842 BOLT (M12X1.75X45-MM)14
8T46483 BOLT (M12X1.75X70-MM)4
8T68684 BOLT (M12X1.75X80-MM)4
15387985 PLATE2
15388006 PLATE2
17379167 CLAMP-HALF8
17379958 PLATE1
19366069 PLATE2
1P370310 SEAL-RECTANGULAR2
1P576711 FLANGE-HALF4
216658912 HOSE AS1
288750213 HOSE AS1
495833814 PLATE1
495834115 PLATE1
570469416 TUBE GP-HYDRAULIC (LH)1
570469817 TUBE GP-HYDRAULIC (RH)1
6V040018 FLANGE-HALF4
7Y453819 CLAMP-HALF8
8T413920 BOLT (M12X1.75X30-MM)12
8T419421 BOLT (M12X1.75X50-MM)10
8T422322 WASHER-HARD (13.5X25.5X3-MM THK)44
