578-6889 WIRING GP-CABS/N BR420001-UP

Group No: 578-6889
Part NumberPart NameQty
20422811 STRAP-CABLE3
8T41982 BOLT (M10X1.5X100-MM)3
3C69693 NUT (M3X0.5-THD)1
3S20934 STRAP-CABLE25
6V94915 SCREW-MACHINE (M4X0.7X20-MM)2
6V96696 SCREW-MACHINE (M3X0.5X8-MM)1
7I22727 BOLT (M5X0.8X12-MM)1
8T03288 WASHER-HARD (5.5X10X1-MM THK)1
8T03379 SCREW-MACHINE (M4X0.7X12-MM)8
8T412110 WASHER-HARD (11X21X2.5-MM THK)3
9X204211 SCREW-TRUSS HEAD (M6X1X12-MM)21
9X204312 SCREW-TRUSS HEAD (M6X1X14-MM)8
096596213 WASHER-HARD (3.4X7X0.8-MM THK)1
096616614 WASHER-HARD (4.5X9X1-MM THK)2
149505015 RELAY (24-VOLT)8
167359316 STRAP1
203900717 NUT (1-1/2-18-THD)1
324568218 PANEL AS1
3245683SEAL1
327995419 CAP (12-PIN CONNECTOR)1
327995520 CAP (1-PIN CONNECTOR)1
335536521 SOCKET-AUXILIARY POWER (12-VOLT)1
431951522 LAMP GP-DOME (12/24-VOLT, LED)1
484145623 STRAP-CABLE1
484906624 FUSE AS1
7Y3952PLUG-CONNECTOR (2-PIN)2
7Y3993TERMINAL-BLADE (12-GA)2
1243548FUSE (30-AMPERE)1
490387525 CABLE AS (CAB)1
6V2369CABLE (4-GA, BLACK)(0.4-M)
9G4343TERMINAL-RING (4-GA, 1/4-IN SCREW)1
3245685RECEPTACLE AS-CONNECTOR (1-PIN)1
3280111PIN-CONNECTOR1
491783126 BASE17
492201027 PANEL AS1
492201228 TIE3
506591129 LOCK-CONNECTOR2
515717830 BRACKET1
528151431 SPEAKER AS2
7Y3951TERMINAL-BLADE (14-GA)2
7Y3954CONNECTOR-PLUG (3-PIN)1
163679532 STRAP-CABLE1
251063733 INSULATION18
270267934 LOCKWASHER1
272584135 RELAY (70-AMPERE)1
427977136 TIE3
490057937 ADAPTER AS4
490058538 ADAPTER AS3
490058839 NUT7
494002240 BASE AS (ANTENNA)1
505763741 PLUG AS-CONNECTOR (2-PIN)4
1690705PLUG-SEAL2
4900571PLUG AS-CONNECTOR (2-PIN)1
505763842 PLUG AS-CONNECTOR (2-PIN)3
1690705PLUG-SEAL2
4900578PLUG AS-CONNECTOR (2-PIN)1
524840343 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)8
8T3490NUT-WELD (M10X1.5-THD)3
524840544 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)2
9X2032NUT-WELD (M4X0.7-THD)4
524840845 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)7
9X2032NUT-WELD (M4X0.7-THD)4
543264746 HARNESS AS-LIGHTING (ROOF)1
578689047 WIRING GP-CAB1
7K118148 STRAP-CABLE6
