System And Components
388-6868 LIGHTING GP-FLOOD -HALOGEN, REACH BOOMS/N HNG1-UP
Group No: 388-6868
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1114836 | 1 CLIP | 17 | |
| 1160118 | 2 CLIP | 1 | |
| 1532521 | 3 LAMP GP-FLOOD (24-VOLT)(BOOM) | 4 | |
| 3990803 | 4 HARNESS AS-LIGHTING (HALOGEN, REACH BOOM) | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 8 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 2434506 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 3990810 | 5 BRACKET | 2 | |
| 2042281 | 6 STRAP-CABLE | 1 | |
| 2048000 | 7 MOUNTING-CABLE TIE | 1 | |
| 6V3265 | 8 CLIP | 2 | |
| 7I2673 | 9 STRAP-CABLE | 4 | |
| 4532834 | 10 BOLT (M16X2X30-MM) | 4 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 3 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 3 | |
| 4512175 | 14 WASHER-HARD (17.5X30X3.5-MM THK) | 4 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 15 | |
| 1757141 | 16 NUT-HEX FLANGE (M10X1.5-THD) | 15 |
