System And Components
382-8284 HOOD & GUARD GP -DOORS/N HNG1-UP
Group No: 382-8284
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3432465 | 1 BUMPER | 1 | |
| 3624352 | 2 ROD | 1 | |
| 3797724 | 3 DOOR GP-ACCESS (RADIATOR, HYD OIL COOLER, FUEL) | 1 | |
| 3797725 | 4 DOOR GP-ACCESS (RADIATOR, ATAAC) | 1 | |
| 3797726 | 5 DOOR GP-ACCESS (PUMP COMPARTMENT) | 1 | |
| 3797736 | 6 STEP AS | 2 | |
| 3852108 | 7 DOOR GP-ACCESS (ENGINE COMPARTMENT) | 1 | |
| 3852124 | 8 DOOR GP-ACCESS (HYDRAULIC TANK) | 1 | |
| 4176526 | 10 DOOR GP-ACCESS (ENGINE COMPARTMENT) | 1 | |
| 4790997 | 11 ROD AS | 1 | |
| 4B4278 | WASHER (10.2X20.5X1.6-MM THK) | 1 | |
| 4515185 | 12 DOOR GP-ACCESS (AIR FILTER, BATTERY) | 1 | |
| 1358572 | 13 BOLT AS | 6 | |
| 1358575 | 14 BOLT AS | 20 | |
| 1358577 | 15 BOLT AS | 6 | |
| 1713396 | 16 GROMMET | 2 | |
| 3B4618 | 17 PIN-COTTER | 2 | |
| 5P0372 | 18 LOCK PIN | 8 | |
| 5P1076 | 19 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 21 NUT (M10X1.5-THD) | 1 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4244 | 23 NUT (M12X1.75-THD) | 6 |
