System And Components
382-7067 LINES GP-FRONT -ELEC CONTROL, ELEC RELIEFS/N HNG1-UP
Group No: 382-7067
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3527063 | 1 CAP | 4 | |
| 3527064 | 2 CAP | 4 | |
| 3709401 | 3 SUPPORT AS | 1 | |
| 3709404 | 4 SUPPORT AS | 1 | |
| 3892500 | 5 VALVE GP-SOLENOID & RELIEF | 2 | |
| 4169467 | 6 HOSE AS | 1 | |
| 4169472 | 7 HOSE AS | 1 | |
| 4169478 | 8 TUBE AS | 1 | |
| 4169480 | 9 TUBE AS | 1 | |
| 4169486 | 10 TUBE AS | 1 | |
| 4169491 | 11 TUBE AS | 1 | |
| 4169493 | 12 PIPE AS | 1 | |
| 4169495 | 13 BLOCK | 1 | |
| 4169497 | 14 PLATE | 2 | |
| 1287514 | 15 CLIP | 4 | |
| 3696859 | 16 PLUG AS | 2 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 3603698 | PLUG | 1 | |
| 1P3706 | 17 SEAL-RECTANGULAR | 6 | |
| 1P4578 | 18 FLANGE-HALF | 8 | |
| 4J0522 | 19 SEAL-O-RING | 5 | |
| 4J0524 | 20 SEAL-O-RING | 1 | |
| 4532839 | 21 BOLT (M16X2X100-MM) | 8 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4139 | 23 BOLT (M12X1.75X30-MM) | 10 | |
| 4471704 | 24 BOLT (M16X2X90-MM) | 8 | |
| 4471711 | 25 BOLT (M16X2X50-MM) | 8 | |
| 8T4196 | 26 BOLT (M10X1.5X35-MM) | 16 | |
| 8T4198 | 27 BOLT (M10X1.5X100-MM) | 4 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 8T4648 | 29 BOLT (M12X1.75X70-MM) | 2 | |
| 8T4956 | 30 BOLT (M12X1.75X35-MM) | 6 | |
| 4471709 | 31 BOLT (M16X2X45-MM) | 4 | |
| 4512175 | 32 WASHER-HARD (17.5X30X3.5-MM THK) | 28 |
